Model NO.
WLD-3D-II
Standard
Standard
Condition
New
Display Accuracy
1′/0.01 /0.1mm
Camber
±2′ ±10°
Caster
±6′ ±20°
King-Pin
±6′ ±20°
Wheel Toe
±2′ ±20°
Set Back
±2′ ±5°
Thrust Angle
±2′ ±5°
Track Width
±2′ 1800mm
Wheelbase
±2′ 3500mm
Post Height
1350mm-2200mm
Transport Package
Export Standard
Specification
CE
Trademark
WLD
Origin
Guangzhou, China
HS Code
9031499090
Production Capacity
5000 Sets/Year
After-sales Service:
Online and Others
Warranty:
12 Months
Type:
3D Wheel Alignment
Certification:
CE
Communication Mode:
Bluetooth Wireless Communication
Structure:
Mechanical
3D Wheel Alignment WLD-3D-II
Display Accuracy 1'/0.01 /0.1mm
Camber ±2' ±10°
Caster ±6' ±20°
King-pin ±6' ±20°
Wheel Toe ±2' ±20°
Set Back ±2' ±5°
Thrust angle ±2' ±5°
Track Width ±2mm 1800mm
Wheelbase ±2mm 3500mm
Post Height 1350mm-2200mm
Advanced software enables the imaging cameras to automatically adjust their height when the vehicle is raised or lowered, ensuring the targets are always in view, and allowing the technician to perform adjustments at a comfortable working height.
Technicians will also enjoy the benefit of being able to perform rolling compensation without lifting the vehicle. The safety and convenience of raising the vehicle to an optimal working height will reduce technician fatigue and correction times, resulting in an increasingly productive workforce and increased profits.
The post must use with lift.
Display Accuracy 1'/0.01 /0.1mm
Camber ±2' ±10°
Caster ±6' ±20°
King-pin ±6' ±20°
Wheel Toe ±2' ±20°
Set Back ±2' ±5°
Thrust angle ±2' ±5°
Track Width ±2mm 1800mm
Wheelbase ±2mm 3500mm
Post Height 1350mm-2200mm
Advanced software enables the imaging cameras to automatically adjust their height when the vehicle is raised or lowered, ensuring the targets are always in view, and allowing the technician to perform adjustments at a comfortable working height.
Technicians will also enjoy the benefit of being able to perform rolling compensation without lifting the vehicle. The safety and convenience of raising the vehicle to an optimal working height will reduce technician fatigue and correction times, resulting in an increasingly productive workforce and increased profits.
The post must use with lift.
