Model NO.
YGB-426
Condition
New
Function
Pipe Flange Welding Turning Positioner
Model
Ygb-426
Welding Pipe Diameter
114-426mm
Motor Power
2.2kw
Welding Positioner Rotate Speed
0-800mm/Min
Positioner Control Mode
Foot Pedal/Control Box
Input Power
AC220V 50jz
Suitable for Pipe Diameter
50-300mm
Tilt Angle
0-45 Dgr
Machine Weight
150kg
Brand
Lemar
Loading Weight
800kg
Lead Time
15 Days
Other Name
Pipe Welding Rotator
Warranty
1 Year
Transport Package
Wooden Box
Trademark
Lemar
Origin
Wuxi, China
HS Code
8428909090
Production Capacity
3000PCS/Year
Type:
Welding Turntable
Structure:
Platform
Rotaion Speed:
0.05-0.5rpm
Max Eccentricity Distance:
200mm
Tilting Angle:
0-120°
Voltage:
110V/220V
110mm-426mm Pipe diameter Welding positioner tilting and rotating rotator
Lemar's main products are:
Pipe automatic welding machine
Pipe prefabricated automatic welding machine
Pipeline Fan automatic welding machine
Fully automatic pipeline automatic welding machine
Pipe welding auxiliary machine (WelDing Positationer, Welding Turing Rolls, Welding Manipulator)
Ring seam pipeline automatic welding machine
Two shots of flange welding
Management of Four Gun Welding
Stainless steel pipeline automatic welding machine
H beam Box beam product line machnes
(CNC Plasma cutting machine/H beam box beam Web Flange assembly machine/H beam box beam Web Flange Submerged arc welding machine/Flange Hydraulic straightening machine/End face milling machine etc.
Specifications:
PIPE POSITIONER with Clamping and Welding Rotator's main performance summary
1. Pipe flange Welding positioner frame: Use steel parts welding structure.
2. Rotor rotation mechanism: The speed of the speed adjustment motor of the variable frequency speed regulating motor, the two active rolling rotation by the gear transmission.
3. Clamping lift mechanism: After the motor drives the reducer, the screw rotation is rotated to drive the clamping arm (and the passive pressure roller on the arm) to move up and down. The transmission chain is equipped with a tight overload protection device to prevent motor drive overload.
4. Flinking mechanism: Driven by a brake motor, after a deceleration transmission such as the reducer and fan -shaped gear, the roller box is centered on both ends of the bearing seat to make a two -way 0 to 45 ° tilt.
5. Electrical control: consisting of electrical control box, hand controller, pedal controller, etc., the electronic control box is equipped with an automatic welding electronic control interface, which can be connected to the welded manipulator for automatic welding.
Lemar's main products are:
Pipe automatic welding machine
Pipe prefabricated automatic welding machine
Pipeline Fan automatic welding machine
Fully automatic pipeline automatic welding machine
Pipe welding auxiliary machine (WelDing Positationer, Welding Turing Rolls, Welding Manipulator)
Ring seam pipeline automatic welding machine
Two shots of flange welding
Management of Four Gun Welding
Stainless steel pipeline automatic welding machine
H beam Box beam product line machnes
(CNC Plasma cutting machine/H beam box beam Web Flange assembly machine/H beam box beam Web Flange Submerged arc welding machine/Flange Hydraulic straightening machine/End face milling machine etc.
Specifications:
| Pressure roller tube flange welding machine | |||
| Model | YGB-426 | Input power supply | AC220V 50HZ |
| Rated Loading | 800kg | Applicable workpiece diameter | Ф114-Ф426mm |
| Motor Power | 2.2KW | Tilt angle | ±45dgr |
| Workbench speed | 0-800mm/min | Brand | Lemar |
| Pressing roller roller lifting method | Handwheel adjustment/Foot pedal | Self -respect | 350kg |
| Standard configuration: Welding positioner welding rotator host, Control cabinet, Foot switch, Power cord, Manual, Qualification Certificate | |||
1. Pipe flange Welding positioner frame: Use steel parts welding structure.
2. Rotor rotation mechanism: The speed of the speed adjustment motor of the variable frequency speed regulating motor, the two active rolling rotation by the gear transmission.
3. Clamping lift mechanism: After the motor drives the reducer, the screw rotation is rotated to drive the clamping arm (and the passive pressure roller on the arm) to move up and down. The transmission chain is equipped with a tight overload protection device to prevent motor drive overload.
4. Flinking mechanism: Driven by a brake motor, after a deceleration transmission such as the reducer and fan -shaped gear, the roller box is centered on both ends of the bearing seat to make a two -way 0 to 45 ° tilt.
5. Electrical control: consisting of electrical control box, hand controller, pedal controller, etc., the electronic control box is equipped with an automatic welding electronic control interface, which can be connected to the welded manipulator for automatic welding.
