Pure-Air PA-300TS-IQ Dental Suction System with UV lights and HEPA filter
Do you realize how serious the threat is around you?
High Volumes of droplets and aerosols are produced by high-speed handpieces and ultrasonic scalers, normal suctions cannot completely remove aerosols. Droplets &Aerosols splash and attach to the dentists faces hair and clothes, blood splash back is produced during treatment.
Aerosols contain bacterial and viral particles unable to be seen by the naked eyes.
Aerosols become attached to the dentists bodies during treatment. virus, Flu Virus and other virus can be spread by droplets aerosols.
Don't worry! We have the pure-Air Dental dust collector Suction System PA-300TS-IQ.
The built in medical ultraviolet light will kill bacteria and viruses effectively as well.
This will help reduce bacterial and viral infections Blood splashing , remove blood spays, to defend against across infection , threat of bacterial and viral infections use it to eliminate airborne bacteria and viruses will help defend dentists and assistants from bacterial and viral infections.
Pure-Air dental suction system PA-300TS-IQ has ultra strong suction power to capture vairous harmful particulates effectively.
PA-300TS-IQ dental dust collector will assemble castors and with acrylic smoke hood, air inlet with 75mm diameter, it will also add UV lights on the bottom.
PA-300TS-IQ dust collector for dental air flow is 300m3/h, with 200W brushless blower, with LCD display and remote control, air flow can be adjustable, it also has warning system to reimind customer to replace filters once they are blocked. With Low noise, bigger suck power, high filtration performance,nice quality, easily move.
It including 3 layers filtration to ensure filtrate harmful material of the fumes completely,
to achieve room air quality standard, protect environment and people's health.
1) 1st layer called F5 class medium efficiency filter pad for remove big particles/smoke/dust (>=85% @ 5um)
2) 2nd layer F8 Class filter to remove smaller particles/smoke/dust (>=95%@0.9 micron)
3) 3rd layer called main filter to remove small particles, smoke and light smells.
It Include 1 layer activated carbon filter & 1 layer H13 class HEPA filter to remove small particles, smoke and light smells.(>=99.97%@0.3micron)
Pure-Air dental dust collector is operates with minimal noise.
The flexibility design of the tubing Arms can be positioned to any angle you need .
3. Product Detail
4. Specification Sheet:
| Equipment Data | ||
| Item | Technical Data | Remark |
| Fume & dust inlet | 50mm / 75mm | Double fume inlets, include 2pc freestanding arms. |
| Fresh air outlet | 100mm | Shutter holes |
| Machine weight | 19KG (N.W.) | Machine with all elements |
| Dimension | 435*250*453mm | Machine size |
| Package dimension | 530*510*560mm | Packed by plywood crate |
| Blower Technical Data | ||
| Item | Technical Data | Remark |
| Running period | more than 30,000h | One year guarantee |
| Max. air flow | 300m³/h | Electronic speed control |
| Input capacity | 200W | Low capacity |
| Air pressure | 2500pa | High pressure |
| Running sound | ≤55dBA | Low sound volume |
| Input power | 110V/220V, 50Hz/60Hz | International standard |
| Filter Elements Data | ||
| Item | Technical Data | Remark |
| Pre-filter PA300-01 | F5 class Primary Filter | Cotton filter pad. |
| F8 Filter PA300-02 | F8 Class medium efficiency filter | Filter can remove 90% of all particles above1 microns |
| HEPA Filter PA300-03-1 | H13 HEPA filter | Filter can remove 99.997% of all particles above 0.3 microns and 95% down to 0.01 micron. |
| Gas Filter PA300-03-2 | Chemical material, life-time 6-10 months | Chemical molecular,Oxidant & Active carbon adsorb noxious gas. |
| Average filtration rate | ≥99.7% | It will be a little fluctuation according to different materials. |
5. Product Description
Pure-Air PA-300TS-IQ laser fume extractor suitable for fume filtration and dust collection for fiber Laser marking metal or laser coding metal. PA-300TS-IQ Air flow is 300m3/h, blower capacity is 200W, it included below 4 layer filters(4kinds filter) to make sure the high air purficiation performance.
1) 1st layer is G3 Primary filter for remove big and heavy particles/smoke/dust(>=5Micron)
2) 2nd layer is F8 medium efficiency bag filter for remove big particles/smoke/dust(>=1Mircron).
3) 3rd & 4th layer is 1pc H13 class HEPA filter combine with 1pc activated carbon filter to remove small particles (>=0.01Mircron) and adsorb smell/toxic gas.
Pure-Air PA-300TS-IQ fume extractor with below specification to make sure high quality and good performance.It's with Low noise, bigger suck power, high filtration performancenice quality, easily move, also with LCD display to show air flow and air pressure, air flow can be adjustable by key switch and remote controller. Product function details as below:
(1) PA-300TS-IQ with one fume inlet and one freestanding arm, for one workstation;;
(2) Air flow can be adjustable during 0m3/h to 300m3/h, from 0CFM to 177CFM;
(3) Four layers filtration to ensure filtrate harmful material of the fumes completely;
(4) It has warning system to remind customer replace filters once they are block heavy.
(5) Strict welding and painting technology achieve to high tightness and corrosion resistance cabinet;
(6) Special sound- absorbing materials reduce operating noise to improve working efficiency;
(7) Taiwan brushless blower, PWM speed control, Alarm system after filter block;
(8) Integrated cabinet with trundle, more freely, small foot print, installed easily, decreasing energy consumption;
6. More Products
7.Exhibition
8.Why Choose Us
10.FAQ
Q: Are you trading company or factory?
A: We are professional factory for making fume extractor, dust collector;
Q: Do you only sell products in name of your own brand PURE-AIR?
A: Except sell in name of our brand, we can also make OEM products and show customer's LOGO;
Q: How long is your delivery time?
A: Normally it is 2-10 days for standard products, for customized products takes 10-20days;
Q: How about your package?
A: We pack goods firstly with stretch film and then pack in strong plywood box, plywood box no need do fumigation.
Q: How long is the quality guarantee of your fume extractor?
A: We can offer 1 year quality guarantee and life-long maintenance of our machine after the warranty period.
