| Technical | Technical Specifications | |
| systems | Language | Chinese/English(can be customized) |
| operation system | Linux | |
| Audio and Video | AHD video input | 1st-channel AHD 1080P(1290*1080) Second, third, fourth channel AHD 720P(1280*720) |
| Audio input | 2-channel audio, PCM format | |
| Audio output | 1-channel audio, PCM format, inner speaker. | |
| ADAS Signal input | 1080P | |
| DSM Signal output | 720P | |
| Live video/Preview | 1/2/4screen split preview | |
| Image resolution | Front 1080P,rear 3channels 720P | |
| Real-time video | 4-channels | |
| Video method | the default:auto recording after power on. | |
| Video storage | File format | H.264 |
| TF card | Double 2units SD Card(Maximum Of Single Card is 256G), loop recording, automatic data coverage | |
| Upgrade | Support remote upgrade | |
| Playback Channel | Support local 4-channel synchronous playback, PC remote single-channel playback | |
| Functional category | Functional categories | sub function | Function description |
| On-board 3G / 4G function | Real-time audio and video | video quality | The video resolution is 720P |
| Upload channel | 3G/4G and WIFI are optional | ||
| Local video | Video quality | The video resolution is 720P | |
| Video mode | Boot video, alarm video, timing video | ||
| Automatic video coverage | Support on/off, when the storage medium is full, automatically overwrite the oldest video data Hard disk version can set backup video or cyclic video mode | ||
| Video programme Arrangement | You can set the video recording schedule from 00:00:00 to 23:59:59 from Monday to Sunday | ||
| Video encoding enabled | You can control the opening and closing of each channel | ||
| Upload video | Remote upload via wifi or 4G is optional | ||
| Power off video data protection | When the main power supply is abnormal, the device can work normally for 15S to ensure that the last data is not lost | ||
| Playback and data backup | Video export | You can export videos through WiFi or remote download (the platform provides the download function), and directly remove the SD card or hard disk to export videos | |
| replay | 1. Multi-channel synchronous playback through HD player 2. Playback is controlled through mobile phone or platform, and mobile phone communicates through WiFi terminal 3. AV screen of the device, play by mouse operation | ||
| Voice intercom | Two-way voice intercom | The platform sends an intercom request or the terminal makes an active request | |
| wireless transmission | 4G | Full netcom: Unicom, Mobile, telecom | |
| Optional built-in WIFI | Optional built-in WIFI module | ||
| Video alarm | EReport | Trigger high and low level reporting through THE IO port, such as braking, left and right turn | |
| Video Loss | Camera video loss alarm reported | ||
| Video shade | Camera occlusion reported | ||
| Voltage alarm | Power hv/LV alarm to platform | ||
| Memory failure alarm | SD card or hard disk fault, TTS playback reminder and upload platform | ||
| active safety | DSM | Fatigue, smoking, phone calls, distraction, occlusion, etc | |
| ADAS | Lane departure, vehicle close, vehicle collision and other alarms | ||
| BSD | Blind area pedestrian alarm | ||
| 794 ministry standard function | GPS data reporting | Real-time data reporting | Report vehicle position information and vehicle status regularly, in line with 808 New Beidou protocol standard |
| Accident suspect data | The suspect data can be extracted remotely by the platform or collected locally by USB | ||
| Fill the data transfer | Automatic retransmission of GPS data, the retransmission protocol supports the 808 New Beidou protocol standard | ||
| BD/GPS alarm management | Out of zone alarm | The platform delivers the regional node, and the equipment determines the location in real time, and the vehicle deviates to report the alarm to the platform | |
| Off-course alarm | The platform delivers line nodes, and the equipment judges the position in real time, and the vehicle deviates to report the alarm to the platform | ||
| Running status alarm | Rapid acceleration, rapid deceleration, sudden brake and other trigger alarm | ||
| Overspeed warning | The platform preset overspeed warning value, TTS voice alert is about to exceed speed | ||
| Overspeed alarm | The equipment preset overspeed threshold, exceed the threshold continuously for 10S, reported overspeed alarm platform | ||
| Ministry standard alarm reporting class | Equipment failure, voltage undervoltage, timeout, terminal failure and other faults reported to the platform | ||
| curfew | The platform sets the stop time, when the vehicle running alarm to the platform | ||
| drowsiness warning system | Platform warning fatigue threshold, the vehicle continuously driving 4 hours without stopping 20 minutes fatigue alarm, TTS voice reminder and report to the platform | ||
| IC card on the alarm | The driver will send alarm data to the platform when inserting and removing the IC card | ||
| Dormancy report | Sleep mode support | After the ACC is disabled, the video recording function is disabled and BD/GPS data is regularly reported | |
| Image capture | Timing captured | Set the timing capture upload platform | |
| Linkage capture | Platform command trigger, IO port trigger, serial port protocol trigger photo uploading platform | ||
| Collecting and setting parameters | parameter acquisition | The platform remotely collects device parameters, including driver identity information, driving information, vehicle information and so on | |
| parameter setting | Platform or network set terminal parameters, including audio and video parameters, BS/GPS related parameters, driving record parameters | ||
| Segmentation speed limit | voice broadcast | Supports segmented rate limiting for platforms and terminals | |
| voice broadcast | TTS broadcast | Supports external TTS voice broadcast | |
| Traffic data recording | Driving condition record | USB data export, in line with GB/T 19056-2012 standard | |
| Accident suspicious records | |||
| Overtime driving record | |||
| Driver's identity record | |||
| log record | |||
| GFP-T | External rod | Oil information | Report the tank level and calculate the remaining oil |
| Abnormal oil volume alarm | Detect abnormal decrease of oil volume and alarm to the platform | ||
| External card reader | The crew information | Report crew information to the platform | |
| External passenger flow machine | Collect passenger flow information | Report the number of passengers information to the platform | |
| Device self-checking | Power On Self Test | After the recorder installation self-check is normal, every time the ignition switch (ACC) is turned on, the positioning, communication, storage and other modules and signal input status should be self-checked first. If the startup self-test fails, the corresponding abnormal information should be displayed and the abnormal self-test status signal of the recorder should be output to the vehicle. | |
| automatic timing corrector | The calibration should be carried out in the parking state | The recorder shall have the function of automatic time correction | |
| device management | On-line Parameter Setting | On-line parameter setting, vehicle information setting | |
| Online Parameter Query | Online Parameter Query | ||
| Device Version Query | Query HIS version and ARM version | ||
| storage medium | query SD card access and current working disks | ||
| WIFI Mode | set client mode, hotspot mode, and advanced assistant mode | ||
| Password change | Factory password setting | ||
| Display Manager | Message display | Comply with GB/T 19056-2012 standard | |
| Backlit Settings | set to long or intelligent on | ||
| contrast | Contrast settable |
ADAS(Advanced Driver Assistance Systems) assist drivers in driving and parking functions for safety and better driving.
ADAS are proven to reduce road fatalities by minimizing human error,
to avoid crashes and collisions by offering technologies that alert the driver problems.
Through a safe human-machine interface, ADAS increase car and road safety.
Driver's fatigue driving,distraction,smoking,phone calls and other behaviors may cause traffic accidents.
Real time monitoring and analysis of driver behavior, voice reminding drivers,
early warning and reporting to CMSV6 platform to avoid traffic accidents.
With BSD algorithm, system can detect pedestrians at the front,side and rear of the vehicle in real time,
avoiding accidents caused by blind spots. Thus, this driving assistance device is essential for large-size vehicles like trucks, buses, construction machines,etc.
Boshijie Technology Co.,Ltd, found in 2009, is a professional manufacturer of MobleDVR, Dashcam, GPS tracker and IoT products in China, which has more than 10 years' specialized experience.
With more than 40,000square meters of industrial park, more than 1,500 staffs (Including 300+ R&D engineers), 23 high speed SMT lines, the daily production capacity of GPS device reaches 40,000units and annual selling quantities reaches 6000,000 units.
BSJ mainly produces MDVR, Dashcam, GPS positioning device,etc. which is suitable for passenger car,logistic vehicles,trucks,buses, school buses, private cars,motorcycle and other vehicles. And we support OEM/ODM services from all over the world.
1. This product enjoys one year of warranty service from the date of installation. During the warranty period, due to non-human factors or equipment damage caused by product quality, please contact the agent in time or call Huizhou Boshijie Technology Co., Ltd. after-sales service department to deal with it.
2. The damage caused by the customer's private revocation or force majeure (such as floods, vehicle accidents) will not be repaired.
3. After the warranty period expires, due to product damage or malfunction caused by the use, the maintenance material cost fee will be charged.
4. Free to provide customers with product purchase, use, installation and other consulting and technical services.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. IT you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q3. What is your terms of delivery?
A: FCA,FOB, CFR, CIF,etc.
Q4. How about your delivery time?
A: Generally, it will take 5 to 7 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can support samples if we have ready stocks.but customers have to pay the sample cost and shipping cost.
