Model NO.
7C-1.5Y
Dumping Direction
Backward
Condition
New
Matched Power
18-22HP
The Form of Damping
Leaf Spring
The Form of Traction
Tripod Traction
The Process of Welding
Carbon Dioxide Jig Welding.
Carriage Dimension
1430*930*330mm
Net Weight
120kg
Type
Full Trailer
Material
Steel
Scale
Light Duty
Components
Trailer Wheels
Transport Package
SKD or as Customers′ Request
Specification
7C-1.5Y
Trademark
MINGSIN
Origin
China
HS Code
87162000
Production Capacity
10000sets/Month
Usage:
Popular Type
Loading Weight:
2T
Certification:
ISO
Structure:
Dump Trailer
Air Brake Type:
Air Inflating
Nosewheel Steering Mechanism:
Wheel Steering
FEATURES:
1. Model: Power tiller trailer
2.0.5T, 1.0T, 1.5T, etc
3.18HP-22HP, etc
4. Popular in Europe or Africa, Asia, etc
0.5T trailer used for the small tiller or some other type machines as the transportation tools for the short distance.
The trailer can match with all kinds of 18-22HP tiller. It's fit for mountain areas, marsh. It mainly used for light-duty transportation. The main characteristic is: Simple and reasonable structure, it can Operates nimbly, dump with manual assistance.
The form of damping: Leaf spring
The form of traction: Tripod traction
Surface treatment: Derusting with large shot blast machine, to change welding stress.
Surface spray coating: Antirusting paint, finishing paint, stoving varnish.
The process of welding: Carbon dioxide jig welding.
The form of transportation: Parts and components, flexible packing with the box plate.
1. Model: Power tiller trailer
2.0.5T, 1.0T, 1.5T, etc
3.18HP-22HP, etc
4. Popular in Europe or Africa, Asia, etc
0.5T trailer used for the small tiller or some other type machines as the transportation tools for the short distance.
The trailer can match with all kinds of 18-22HP tiller. It's fit for mountain areas, marsh. It mainly used for light-duty transportation. The main characteristic is: Simple and reasonable structure, it can Operates nimbly, dump with manual assistance.
The form of damping: Leaf spring
The form of traction: Tripod traction
Surface treatment: Derusting with large shot blast machine, to change welding stress.
Surface spray coating: Antirusting paint, finishing paint, stoving varnish.
The process of welding: Carbon dioxide jig welding.
The form of transportation: Parts and components, flexible packing with the box plate.
| Model | 7C-1.5Y |
| Loading capacity (kg) | 1500 |
| Overall dimensions (mm) | 3100*1050*1836 |
| Model of tyre | 6.50-16 |
| Weight (kg) | 446 |
| Brake form | Inertia brake |
| Unloading form | Rear tipping |
| Carriage size (mm) | 2000*1000*460 |
