Model NO.
1200x1000
Color
Black, Grey
Sleeve Material
Bubbleguard Sheet
Loading Capacity
300-500kg
Transport Package
Pallet
Specification
1200x1000x1000mm
Trademark
AisPak
Origin
Qingdao
HS Code
3923900000
Production Capacity
500sets/Day
After-sales Service:
Available
Warranty:
12months
Capacity:
500-1000L
Application:
Auto Parts
Material:
HDPE
Type:
Open
Plastic Foldable Large Container
Foldable large container is a versatile 'sleeve pack' system consisted of 3 parts: Lid, Sleeve and Pallet, designed to store and transport more products in less space. Pallet sleeve box can be completely collapsed when empty for efficient reverse logistics.
The twin-sheet thermoformed Lid and Pallet deliver high strength and load-carrying capacity without increasing the weight of the packaging. The reasonably designed walls and ribs provide larger internal dimensions and carrying capacity. Lid and Pallet are designed with nine feet base for anti-skid stable stacking and compatibility with all standard forklifts for easy handling.
Sleeve
The Sleeve, made of high strength, high payload polypropylene structural material referred to as "honeycomb", with high physical durability and light-weight. It's impressive impact and compressive strength due to air-lock technology keeps damage at bay during rough transportation.
| NO. | EXTERNAL DIMENSIONS (in mm) | INTERNAL DIMENSIONS (in mm) | PALLET WEIGHT (in kg) | LID WEIGHT (in kg) | INTERNAL HEIGHT (in mm) |
| 1 | 1470 x 1150 | 1400 x 1070 | 15 | 13 | T.H.-200 |
| 2 | 1350 x 1150 | 1280 x 1070 | 14 | 12 | T.H.-190 |
| 3 | 1150 x 1150 | 1105 x 1105 | 10.5 | 8.5 | T.H.-170 |
| 4 | 1100 x 1100 | 1055 x 1055 | 10 | 8 | T.H.-170 |
| 5 | 1150 x 985 | 1106 x 940 | 10 | 8 | T.H.-170 |
| 6 | 1200 x 1000 | 1140 x 950 | 10 | 8 | T.H.-170 |
| 7 | 1200 x 800 | 1160 x 760 | 8.5 | 7.5 | T.H.-170 |
| 8 | 1220 x 1150 | 1160 x 1080 | 12 | 10 | T.H.-200 |
| 9 | 1600x1150 | 1540x1080 | 19 | 14 | T.H.-200 |
| 10 | 2070x1150 | 2000x1080 | 26 | 16 | T.H.-200 |
| 11 | 800x600 | 760x560 | 6 | 5 | T.H.-200 |
| 12 | 1230x1030 | 1180x980 | 10 | 8 | T.H.-200 |
| ★ Sleeves Height is Customized | |||||
