Model NO.
KPX
Wheel Tread(mm)
Customized
Certificate
ISO9001, SGS, CE
Power Supply
Battery
Running Distance
Unlimited
Operation
Hand Pendant + Remote Control
Transport Package
Generally According to Customers′ Demands.
Specification
GB/T6127-92
Trademark
BEFANBY
Origin
Xinxiang, Henan, China
HS Code
8428909090
Production Capacity
100 Sets/Month
Color:
Gray, Blue, Red, Yellow, Customized
Warranty:
2 Years
Load Capacity(T):
1-1500ton
Table Size(mm):
Customized
Speed(M/Min):
20
Wheel Diameter(mm):
Customized
Electric Driven Flat Track Transport Trolley with Remote Control
| 1. Product Introduce about the Electric Driven Flat Track Transport Trolley with Remote Control | Electric Driven Flat Track Transport Trolley with Remote Control is one of our common and mature product, which is customized as per customers' true demand. Such as power supply, operation system, control system, track or no track, steerable, wheelstype, cart frame structure and so on, and then provide proper solution to you. |
| 2. The feature of the custom rail transport trolleys | 1. The running distance is unlimited. 2. The battery power transfer car can turn and run on "S" or curved tracks. 3. Suitable for all kinds of environments.It can be used indoors or outdoors in high temperature explosion-proof and other environments.Suitable for long distance operation. 4. Plc system can be equipped to realize automated handling. 5. Safe operation system with (sensor stop, sound&light alarm, buffer, E-stop, etc.) 6. Customized for you.Custom table size, operating speed,load,etc.Meet your requirements. |
| 3. Working Principle of the Electric Driven Flat Track Transport Trolley with Remote Control | This kind of Electric Driven Flat Track Transport Trolley with Remote Control is powered by battery, The battery is installed in the car, and supply DC electricity to the control system, which makes the cart start, stop, go forward, back forward and so on.It is consist of battery, motor, reducer, cart frame, electric appliance, etc. |
| 4. Advantage of the Warehouse use automatic transportation rail mould flatbed trailer | 1. Load Capacity reach to 1-1,500 tons can be customized on request. 2. Safe bearing factor reach to 150% 3. All transfer cart with safety control system. 4. Stout steel frame.(adopt the box girder structure) 5. Free provide customized handling solution 6. Automated operation and transportation system are support 7. DC & AC motor supported 8. Promote the working frequency and save the labor cost 9. Low noise and environmental protection 10. Solve the problems of limitation of the crane 11. More than 20 years' export experience. 12. Professional after-sales service team. 13. Professional design drawing for the confirmation in case of any misunderstanding. 14. BEFANBY have passed various qualification certifications.CE ISO SGS approved... |
| 5. BEFANBY Company Introduce | Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd (BEFANBY) is a professional and experienced manufacturer and exporter of material transfer cart in China.Our company has been producing material transfer carts since 2003.We provide customized ergonomic solutions for specific load mobility requirements.Our products have passed the authentication of Quality system ISO9001, and SGS, CE certifications. All of our products accord with machinery industrial standard JB/T61 27-92. |
6. Parameter List---- Electric Driven Flat Track Transport Trolley with Remote Control
| Model | KPX-2T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-63T | KPX-150T | |
| Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
| Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
| Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
| Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | |
| Wheel Diameter(mm) | Ф270 | Ф300 | Ф350 | Ф400 | Ф500 | Ф600 | Ф600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
| Running speed (min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
| Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
| Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
| Running Time When Full Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
| Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
| Reference Weight (t) | 2.8 | 4.2 | 5.9 | 6.8 | 8 | 10.8 | 26.8 | |
| Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | QU100 | |
| Remark | The technical parameter of the electric transfer cart only can be make reference above.All can be customized manufacturing as per your true demand. please contact us if any doubt. Our professinal engineer will help you solve the transfer problems in any time. | |||||||
7. Packing and Delivery
8. How to choose the suitable transfer carts?
All of our railway transfer carts, all customized as client's requirement, for choose the most suitable handling trolley,pleasekindly providing the following information:
· Transfer or handling what material/cargo?
· What capacity do you need?
· This transfer vehicle is running on rails or ground(floor)?
· Your requirement for table size:length,width and height?
· How about the running distance?
The above is for reference only, all are customized on demand.just one minutes to send inquiry to us, BEFANBY has help you well to get your economic handling solution and quotation despite whether further cooperation or not.
