Model NO.
KPX-50T
Type
Power Pallet Truck
Entry Type
2-Way
Colour
Customized
OEM
Accepted
Operation
Hand Pendant + Remote Control
Transport Package
According to The Customers′ Demands
Specification
JB/T6127-92
Trademark
BEFANBY
Origin
Yulin Township Yanjin Country,Xinxiang,Henan,China
HS Code
84289090
Production Capacity
100 Sets/Month
Color:
Gray, Blue, Red, Yellow, Customized
Warranty:
2 Years
Certificate:
CE ,ISO9001,SGS
Capacity:
1-1500t, Customized
Material:
Steel
Style:
Steel Box and Girder
Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
Working principle---- Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
Application Show----Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
Advantages Show----Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
· Safe and environment friendly
· Big starting power
· Small impact to the gear reducer
· No restriction of the running distance
· Can running on s-shape rail, arc-shape rails
· Has no limit on working distance
· Anti-explosion,Anti-high temperature
· Stable start, big starting power, long lifetime
. The largest capacity can be reach to 500T.
Parameter List---- Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
Processing of Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
Introduction Of BEFANBY Company
Our Retated Product You may interesed in
How to choose the suitable transfer cart?
All of our rail transfer cart all customized as client's requirement, for choose the most suitable handling trolley,please kindly providing the following information:
· Transfer or handling what material/cargo?
· What capacity do you need?
· This transfer trolley is running on rails or ground(floor)?
· Your requirement for table size:length,width and height?
· How about the running distance?
. How many hours does the transfer cart work one day?
 | Special Platform Transfer Trolley for Heavy Transportation (KPX-50T) is one of our common and mature product, which is customized as per customers' true demand. Such as power supply, operation system, control system, track or no track, steerable, wheelstype, cart frame structure and so on, and then provide proper solution to you. |
 |  |
Working principle---- Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
This kind of Special Platform Transfer Trolley for Heavy Transportation (KPX-50T) is powered by battery, The battery is installed in the cart, and supply DC electricity to the control system, which makes the cart start, stop, go forward, back forward and so on.It is consist of battery, motor, reducer, cart frame, electric appliance, etc. |
Application Show----Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
The material handling rail transfer cart for heavy material can be used in many occasions, due to its simple structure, despite of the plant or assembly line, warehouse or port for heavy equipment, industry material, mold... only exists tracks, and the battery is charged fully,it can transport anywhere. |
 |
 |  |
Advantages Show----Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
· Safe and environment friendly
· Big starting power
· Small impact to the gear reducer
· No restriction of the running distance
· Can running on s-shape rail, arc-shape rails
· Has no limit on working distance
· Anti-explosion,Anti-high temperature
· Stable start, big starting power, long lifetime
. The largest capacity can be reach to 500T.
Parameter List---- Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
| Model | KPX-2T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-63T | KPX-150T | |
| Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | 150 | |
| Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 | 10000 |
| Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | 1200 | |
| Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | 7000 | |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | |
| Wheel Diameter(mm) | Ф270 | Ф300 | Ф350 | Ф400 | Ф500 | Ф600 | Ф600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 | |
| Running speed (min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | 15 | |
| Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | 600 | |
| Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | 72 | |
| Running Time When Fu ll Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | 2.9 | |
| Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | 265.2 | |
| Reference Weight (t) | 2.8 | 4.2 | 5.9 | 6.8 | 8 | 10.8 | 26.8 | |
| Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | QU100 | |
| Remark | The Special Platform Transfer Trolley for Heavy Transportation (KPX-50T) only can be make reference above.All can be customized manufacturing as per your true demand. please contact us if any doubt. Our professinal engineer will help you solve the transfer problems in any time. | |||||||
Processing of Special Platform Transfer Trolley for Heavy Transportation (KPX-50T)
Introduction Of BEFANBY Company
Our Retated Product You may interesed in
| Product Name | Model No. | Power Supply Mode | Load Capacity | Other Items | Usage |
| Rail Transfer Cart | KPD | Conductor Rail | Load range 1-300ton, can be customized per client demand | Running distance | Ordinary goods,such as steel plate, workpiece,equipment etc special goods,such as coil. column,ladle etc |
| Battery Powered Transfer Car | KPX | Battery | Using frequency | ||
| Motorized Transfer Trolley | KPJ | Cable Drum | Running distance | ||
| Busbar Powered Handling Cart | KPC | Busbar | Working shop | ||
| Towed Rail Trailer | KP | Tractor | 1-100t | Working shop | |
| Steerable Towed Car | BWT | Tractor | Load range 1-50t, less than 20t, cement floor is ok. More than 20t,steel floor is demanded. | Working environment | |
| Trackless Handling Machine | BWP | Battery | Working path |
How to choose the suitable transfer cart?
All of our rail transfer cart all customized as client's requirement, for choose the most suitable handling trolley,please kindly providing the following information:
· Transfer or handling what material/cargo?
· What capacity do you need?
· This transfer trolley is running on rails or ground(floor)?
· Your requirement for table size:length,width and height?
· How about the running distance?
. How many hours does the transfer cart work one day?
