Model NO.
Q235
Certification
ISO9001, CE
Type
Railway
Keyword
Stainless Steel Rail
Keywords
Steel Rail
Iron Wire (PCS/Bundle)
75
Tolerance
1%
Application
Railway Rail
Standard of Products
Q/Yg001-2014
Specificaton
4kgs/M
Length of Dimension
6(M),8(M)
Transport Package
Wooden Box
Specification
63.69kg
Trademark
Chinacoal
Origin
China, Shandong, Jining
Production Capacity
10ton/Day
After-sales Service:
Video or Technical Support
Warranty:
1year
Customized:
Customized
Introduction of Q235 Type Railway Steel Light Rail Mine Rail Road Steel Railway Steel RailNormally, steel rail is devide into light rail ,heavy rail and crane rail.
(1)Light rails: 6kg/m,9kg/m,12kg/m,15kg/m,18kg/m,22kg/m, 24k/mg, 30kg/m Material: Q235B / 50Q / 55Q Length of each piece: 6m~12m Executive standard: refer to GB11264-89
(2)Heavy rails: 38kg/m, 43kg/m, 50kg/m, 60kg/m Material: U71Mn / 50Mn / 44Mn Length of each piece: 12m,12.5m Executive standard: refer to GB2585-2007
(3)Crane rails: QU70,QU80,QU100,QU120 Material: U71Mn Length of each piece: 12m,12.5m Executive standard: refer to GB3426-82
Parameters of Q235 Type Railway Steel Light Rail Mine Rail Road Steel Railway Steel Rail| THE LIST OF YYGT | ||||||
| Name of Commodity | Specificaton | Materials (Steel Grade) | Standard of Products | Theory Weight (kgs/M) | Length of Dimension (M) | Packed In Bundle With Iron Wire (pcs/bundle) |
| Light Rail | 4kgs/m | Q235 | Q/YG001-2014 | 4kgs/m | 6,8 | 75 |
| 8kgs/m | Q235 | Q/YG001-2014 | 8.42kgs/m | 55 | ||
| 12kgs/m | Q235 | GB11264-2012 | 12.2kgs/m | 36 | ||
| 15kgs/m | Q235/55Q | GB11264-2012 | 15.2kgs/m | 6,8,9,10 | 28 | |
| 18kgs/m | Q235/55Q | Q/YG001-2014 | 18.06kgs/m | 21 | ||
| 22kgs/m | Q235/55Q | GB11264-2012 | 22.3kgs/m | 21 | ||
| 24kgs/m | Q235/55Q | Q/YG001-2014 | 24.46kgs/m | 21 | ||
| 30kgs/m | Q235/55Q | GB11264-2014 | 30.1kgs/m | 15 | ||
| Heavy Rail | 38kgs/m | U71Mn | GB2585-2007 | 38.733kgs/M | 12,12.5 | 10 |
| 43kg/m | U71Mn | GB2585-2007 | 44.653kgs/M | 10 | ||
| 50kgs/m | U71Mn | GB2585-2007 | 51.514kgs/M | 10 | ||
| 45/50Mn | Q/YYG002-2008 | 31/34/36/39/41kgs/M | 12,12.5 | 10 | ||
| Crane Rail | QU70 | U71Mn | YB/T5055-93 | 52.8kgs/m | 12 | 10 |
| QU80 | YB/T5055-93 | 63.69kgs/m | 10 | |||
| QU100 | YB/T5055-93 | 88.96kgs/m | 5 | |||
| QU120 | YB/T5055-93 | 118.1kgs/m | 5 | |||
Photos of Q235 Type Railway Steel Light Rail Mine Rail Road Steel Railway Steel Rail
