Model NO.
80L
Maximum Torque
8.8kn
Maximum Working Radius (Bidirectional)
1650mm(Customizable)
Transport Package
Nude Packing
Specification
6100*2800*2650mm
Trademark
JingGong
Origin
China
HS Code
8429521200
Production Capacity
3000units/ Year
After-sales Service:
Supported
Warranty:
1 Year
Customized:
Customized
Certification:
ISO9001
Type:
Ballst Cleaning
Rotation Speed (High Speed / Low Speed):
30-60r/Min
As one of the earliest designed and developed excavators in our company, JG80L tracked excavator provides comprehensive and mature techniques. Undercutting is frequently performed as an independent service for cleaning stretches of track. It is also deployed as part of larger maintenance of way and environmental projects.
This mini crawler excavator specifically designed for use off-track cutting ballast, is a revolutionary system designed to undercut track without wasting valuable track time, scooping out contaminated gravel and mud and fouled ballast from beneath railroad tracks.
| SPECIFICATIONS | ||||||||||
| RANGE OF OPERATION | Boom length | 3300mm | ||||||||
| Arm length | 1850mm | |||||||||
| Maimum digging force | 45KN | |||||||||
| Back-end radius of gyration | 1800mm | |||||||||
| Max. Opening Width of Grab | 650mm | |||||||||
| Min. Opening Width of Grab | 200mm | |||||||||
| Max. RADIUS Grabing Weight | 0.5~0.6t | |||||||||
| Max,Width of Grab | 2800mm(customizable) | |||||||||
| Grapple rotation angle | 360° | |||||||||
| DIMENSION | (Length*width*height) travel position | 6100*2800*2650mm | ||||||||
| Wheel base | 2600mm | |||||||||
| Track Gauge | 1570mm | |||||||||
| Width Of Crawler | 400mm | |||||||||
| Ground clearance of counterweight | 780mm | |||||||||
| Min ground clearance | 280mm | |||||||||
| TECHNICAL PARAMETERS | Applicable railway gauge | 1435mm(customizable) | ||||||||
| efficiency | ≥40pic/h | |||||||||
| Angle of rotation | 360° | |||||||||
| Machine weight | 8000kg | |||||||||
| Engine model | YUCHAI | |||||||||
| Rated Power | 48KW | |||||||||
| Rated Speed | 2200r/min | |||||||||
| Hydraulic system working pressure | 21Mpa | |||||||||
| Hydraulic system flow | 120L/min | |||||||||
| Metering gear pump | 2*28ml/r | |||||||||
| Max Hauling force | 45KN | |||||||||
| (High speed/low speed) | 4.5/2.5km/h | |||||||||
| Grade Climbing ability | 70%/35° | |||||||||
| Volume Of Bucket | 0.25m3 | |||||||||
| Revolution Overdrive Pressure | 16Mpa | |||||||||
| Full circle swinging time | 5.5s | |||||||||
| Fqt Fuel Quantity | ≥4L/h | |||||||||
| Capacity Of The Fuel Tank | 110L | |||||||||
| Hydraulic Tank Capacity | 110L | |||||||||
