| Electric system | |
| Motor | Light weight high speed brushless |
| DGW 500W rear hub motor (Shengyi/Bafang) | |
| Battery | 48V,10.4Ah native/Samsung Li-ion battery |
| 48V,14Ah native Li-ion battery | |
| PAS | Thumb-throttle |
| Controller | intelligent bruhsless. |
| Charger | AC 100V -240V 2amps smart charger |
| Charging time:4-6hours | |
| Performance | |
| Max speed | 25km/h (EU),35km/h (USA & Canada). |
| Max Climbing Ability | 40~45° |
| Range | 20~30km with 48V/10Ah li-ion battery(throttle). |
| Max Climbing Ability: 40° | |
| Max load | 120kgs |
| Net weight | 24kgs |
| Gross weight | 27kgs |
| Container load | 90pcs/20ft container,180pcs/40ft container |
| Display | Smart LCD display |
| Main components | |
| Frame | 6061 aluminium alloy. |
| Tyres | 20*4.0 CST/Kender fat tyre |
| Rim | Al alloy double wall and CNC side wall. |
| Front fork | Al alloy with suspension function(TGS/MOZO) |
| Front brake | TEKTRO disk brake |
| Rear brake | TEKTRO disk brake |
| Speed gears | NO |
| Rear derailleur | NO |
| Stem | al alloy foldable (Promax) |
| Brake lever | Promax/TEOTRO brake lever with power-off function |
| Chain | NO |
| Mudguard | YES |
| Lighting | LED front & rear light with hall |
| Packing size | 155 x 29 x 69cm special for exporting |
More pictures
CERTIFICATION
FAQ
1.Q: Can I get some samples?
A: Yes,sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: It usually takes about 15 working days for samples,25-30 working days for mass production based on specifications for your order and quantity.
3. Q:What's your payment terms?
A: We usually accept T/T or L/C at sight as the main payment terms,and
other payment can also be negotiated.
4. Q: Do you have the products in stock?
A: YES, we made some hot-sale electric bike stocks. .
5. Q: Can I mix different models in one container?
A: Yes, different models can be mixed up in one full container.
6. Q: How does your factory do regarding the quality control?
A: Quality is priority. We always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before packing and shipping.
Service&Warranty
- Frame: 3 years quality warranty.
- Battery: we provide 24 months quality guarantee for Li-ion battery.
- Electric motor: we provide as long as 12 months quality warranty.
- Charger: we provide 12 months quality warranty.
- Controller: we provide 12 months quality warranty.
