Model NO.
TE18D
Recommended Fuel
Unleaded Gasoline
Ignition System
Cdi
Control System
Tiller Handle
Starting System
Manual
Starting Carburation System
Choke Valve
Gear Position
Forward-Neutral-Reverse
Item
Gasoline Boat Motor with Ce/SGS
Transport Package
Carton
Specification
CE, SGS, ISO9001
Trademark
EARROW
Origin
Zhejiang China
HS Code
8407210000
Production Capacity
20000 Units/Year
Cylinders:
2
Fuel Type:
Gasoline
Engine:
2 Stroke
Engine Position:
Outboard
Condition:
New
Usage:
Outboard Engine, Motor
Specifications
1. Lower Noise
2. More Stable
3. Factory price
4. Beautiful shape and appearance
5. Top cover more durable
6. Various engine series
7. New design
Series:
Two stroke:3hp;5hp;9.9hp;15hp;30hp;40hp;
Four stroke:2.5hp;4hp;6hp
Certification
CE/SGS/ISO 9001
ITEM:Marine outboard engine two-stroke
Advantages
- High grade marine aluminum alloy for ultimate corrosion protection
- Tilt & trim with shallow water drive various positions
- Low oil indicator for increased protection
- Twist grip throttle control for easy maneuverability & safety
- Thermostat controlled water cooling system
- Safety lanyard with emergency shutoff
- Easy forward-neutral-reverse gear shifting
- Vibration reduction system for smooth performance
- Start in gear protection for increased safety
- Adjustable steering friction for easier maneuverability
- CDI ignition system for trouble free starting
- Innovative large recoil wheel assists easy starting
- Quiet, through the propeller hub exhaust
- Quality 24L fuel tank with hose
- Colors: Jewelry blue, Pearl white, Dark grey
Details
- production time: 20 days after order confirm and receive 30% deposit
- CE standard, FOB Ningbo, USD currency
- MOQ: 1~10 unit
- shade material details pls check attached quotation sheet
- packing details as attached also
- samples: 2 working days, we keep stock. Freight collect. Courier cost need to check with express when packing finished.
About Us
We are Chinese professional outboard motor manufacturer. All our outboards are CE approval and our factory is ISO9001 qualified.
Our product range is from 2.5hp to 40hp,both two and four stroke are available.
Philosophy
Quality First, User-oriented Management, Dedication to customer services
R & D Team
OEM service available;
All of our key engineers came from the previous BRP outboard factory of China DG, with more than 20 years' experience.
Product Series
We have both 4 and 2 stroke series, we also have 4 stroke propane engines which are more environment friendly. Almost plastic and die casting parts are made by ourselves, almost parts are made by Aluminum and treated by special surface treatment, so that we could control the quality serious, it is anti-corrosion and easy to carry.
Warranty
1 year for commercial usage;
1 year for pleasure;
Port of Load
Ningbo, our factory is located in Yongkang Zhejiang China, the over street is a container storage yard. Very convenient for delivery.
| Model | TE18D |
| Dimension | Overall length: 878mm (34.6 in) |
| Overall width: 363 mm (14.3in) | |
| Overall height S:1062mm (41.8in) | |
| Overall height L: 1189 mm (46.8in) | |
| Weight | S: 38 Kg |
| L: 40Kg | |
| Full Throttle Operating Range | 4500-5500 r/m |
| Maximum Output | 11kw/18hp |
| Idling Speed | 1050±50r/m |
| Type | Two Stroke |
| Displacement | 246cc |
| Bore×Stroke | 56.0×50.0mm |
| Ignition System | CDI |
| Spark Plug | NGK B8HS-10 |
| Spark Plug Gap | 0.9-1.0mm |
| Control System | Tiller Handle |
| Starting System | Manual |
| Starting Carburation System | Choke Valve |
| Gear Position | Forward-Neutral-Reverse |
| Gear Ratio | 2.08 (27:13) |
| Trim and Tilt System | Manual Tilt |
| Recommended Fuel | Unleaded Gasoline |
| Recommended Engine Oil | 2-stoke outboard motor oil |
| Fuel Oil Ratio | 50:01:00 |
| Gear Oil | 0.250L |
| Fuel Tank Capacity | 24 L |
