Tank Volume
＜5000L
Drive Wheel
4×2
Seats
≤5
Horsepower
＜150hp
Engine Capacity
＜4L
Storage
Oil
Tire Certification
ISO
Tire Design
Radial
Condition
New
Gearbox
6 Forward & 1 Reverse Gear
Chassis Brand
Dongfeng, Isuzu, Foton, JAC, etc.
Tanker Volume
3m3, 4m3, 5m3, 6m3, 8m3, 10m3, etc.
Tank Material
Carbon Steel, Stainless Steel or Aluminum Alloy
Tank Shape
Square Round, Round
Oil Type
Diesel, Petrol, Gasoline, Oil, etc.
Oil Pump
Chinese Famous Brand
Oil Dispenser
Chinese Famous Brand
Hose Reel with Filling Gun
15 Meter (Length Can Be Longer as Per Request)
Oil Vapor Recovery System
Optional
Delivery Time
35 Days
Other Equipment
with Oil Dispenser, Oil Bowser
Transport Package
Naked, Container, RO-RO, Bulk
Specification
5995*2050*2500mm
Trademark
CLW
Origin
Suizhou, China
HS Code
87059099
Production Capacity
500 Units/Month
After-sales Service:
with After Sales Service
Warranty:
One Year
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
1-10t
Emission Standard:
Euro 3
FOTON AUMARK-S33 4x2 5000 Liters Small Mini Fuel Dispenser Truck Oil Refueling Tank Truck With Oil Filling Machine
Description:
1. Fuel tank truck (also called fuel bowser, diesel tanker truck, oil tanker truck, oil bowser, petrol tanker, crude oil tanker, refuel tanker truck) is used to transport oil, diesel, gasoline, kerosene, etc.
2. Fuel bowser can be divided into many compartments to transport different types of fuels, lubricant, crude oil, alcohol...
3. The fuel truck can be equipped with oil pump and refueling machine, all for easy operation.
4. Super powerful engine, no overhaul within 100,000 km.
Specifications:
| Vehicle model | AUMARK-E33 | |
| Cabin | Single row/W1880/left rudder | |
| Whole vehicle main dimensions | Overall dimensions (LxWxH)mm | 5965×1960×2225 |
| Wheel base(mm) | 3360 | |
| Weight data | Curb weight(kg) | 2300 |
| Gross vehicle weight(kg) | 7500 | |
| Persons in cab | 3 | |
| Whole vehicle main performance | Max. speed(km/h) | 100 |
| ENGINE | Model | BJ493ZLQV1 |
| Emissions standards | Euro-3 | |
| Displacement(L) | 2.771 | |
| Rated Power(kw/rpm) | 80 | |
| Max torque (N.m/rpm) | 280 | |
| Gearbox | Model | 5S368 |
| Front axle | Type/Mainreducetion ratio | 2.4T |
| Rear axle | Type/Mainreducetion ratio | 4.5T/5.714 |
| Suspension | Front suspension/Leaf spring number | 3 |
| Rear suspension/Leaf spring number | 8+6 | |
| Brake system | Service brake | Drum pneumatic braking |
| Parking brake | Brake gas brake | |
| Auxiliary brake | Engine exhaust brake | |
| Wheels and tyre size | 6+1/( 7.00R16) | |
| Tank | top color | optinal |
| Volume | 4m3 | |
| Tank material and thickness | Part of the tank material,thickness:Q235B carbon steel, 4mm Head material and thickness: Q235B carbon steel, 5mm | |
| Emergency shut-off valve | Quantity: 1 Material thickness: aluminum alloy | |
| Manhole cover | Quantity: 1 Diameter: 500mm | |
| Oil pump and pipeline | Oil pump, seamless steel pipe; Pump flow: 30m³/h; Pump pressure: 0.6Mpa; Speed: 960r/min; Shaft power: 7.1KW | |
| Pump inlet and outlet | Specification: choose one of DN50/DN65, aluminum alloy Control method: manual | |
| Refueling reel and fueling gun | 15m automatic return reel nozzle | |
| Fuel dispenser | Three gold medals Chinese and English fuel dispenser (with ticketing function) | |
| power takeoff | SDQ51-38PQ1 (flange output) or SDQ51-38LGQ1 (spline output) | |
| Climb the ladder | Welded independent climbing ladder at the end of the tank-movable European style climbing ladder with anti-skid board | |
| Top guard | Protective handrails are installed on both sides of the top of the tank-aluminum alloy folding guardrail Anti-skid plate installed on the top of the tank-anti-skid walkway | |
| Tube box | Number: 2 Installation position: one on each side of the tank Specifications: The length of the tube box is the same as the tank body, and the cross section is circular Water diversion pipe: each pipe box has a built-in water diversion pipe with male and female end joints. The joint model is DN50/DN65. | |
| Fire extinguisher barrel | Material: Q235 Quantity: 2 | |
| Fire extinguisher | Specification: 4KG Quantity: 2 | |
| exhaust pipe | Rear to front | |
| Electrostatic device | Metal electrostatic plate, electrostatic belt device: 1 each | |
| Subframe | Tank bottom auxiliary beam | Made of Q345 carbon steel plate |
Different Fuel Tank Trucks:
The CLW group, which was appointed by the Development and Reform Committee of China. CLW group is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.
Products Catalog:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
