Model NO.
CLW
Seats
≤5
Horsepower
351-450hp
Engine Capacity
6-8L
Tire Certification
ECE, GCC, DOT
Tire Design
Radial
Condition
New
Product Name
Tractor Truck
Product Brand
Dongfeng
Size
7060X2500X3030
Gross Vehicle Weight (Kg)
25000
Cabin
One Sleeper Bed Two Sleeper Bed
Driving Style
Left Hand Drive or Right Hand Drive
Air Conditioner
with A/C
Driver Seat
Air-Supporting Driving Seat
Package
Bulk, RO-RO, Container, Naked
Transport Package
RO-RO Bulk Naked Container
Specification
ISO, CCC, CE, ASME, ASTM, EEC
Trademark
CLW
Origin
Hubei China
HS Code
8701901190
Production Capacity
100000PCS/Year
Warranty:
One Year
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
21-30t
Emission Standard:
Euro 3
Drive Wheel:
6×4
Introduction of dongfeng 6x4 truck head
Technology - adopting everyone's merit to make itself leading
The engine of Dongfeng tractor are all America brand, it is with strong power, large towing capacity,
1.The cab of Dongfeng tractor truck style is sturdy but elegant. The driving space is very large and the high roof with double sleeper is very suitable for long-distance transport.
2.The shape looks doughty and also looks flexible and streamline, which not only shows the rough vigor but
also accords with oriental aesthetic viewpoint.
3.The solid Dongfeng Logo with two swords shows a kinglike air.Drive this vehicle and you will enjoy the sense of success.
4. Dongfeng Tianlong has a wide range of power 230-420 horsepower.
5.Dongfeng new generation 13-t single and double heavy wheel axleadopts international technology with the quality
of "gear-impact resistance,large loading, big twisting moment and long life-span".
6.The steel wire tyre and Nylon tyre are optioanl for dongfeng tractor truck head
| Description | DONGFENG TL 6X4 Tractor | ||
| Drive Model | 6X4, LHD/RHD | ||
| Fuel type | Diesel | ||
| Vehicle Main Dimensions | Dimensions(L x W x H)mm | 6960×2500×3030 | |
| Wheel base (mm) | 3300+1350 | ||
| Overhang (front/rear) (mm) | 1500/810 | ||
| Wheel track (front/rear) (mm) | 1940/1860 | ||
| Approach/Departure angle(°) | 18/32 | ||
| Weight in KGS | Curb Weight | 8500 kg | |
| GVW. | 25000 kg | ||
| Trailer total mass | 39990 | ||
| Max. driving speed(km/h) | 95 | ||
| Axle-load(kg) | 7000/18000/18000 | ||
| Allowable passengers in cab: | 3 | ||
| Engine | Model | ISLe315 30 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 315HP | ||
| Emission standard | Euro III | ||
| Gearbox | Fuller16+1reserve | ||
| Clutch | Φ430mm | ||
| Cab | D310-H1(high crowned two-bedroom, standard) | ||
| Operation control system | Electrically hydraulic control | ||
| Fuel tank of the engine (L) | 300L | ||
| Tire | 315-80R22.5,11 tires , 10 pcs+ 1 spare tire | ||
| Equipment | Air bag seat,Adjustable steering wheel,Two visors,Cigarette lighter, Radio cassette recorder,Tiltablecabin,Power boosting steering gear, Manual rear-view mirror and glass lifter | ||
ClW Heavy Industry Co., Ltd
LPG tank is our most advantage key products which rank Top 5 in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.
1.Competitive Price and Excellent Quality,
2.More than 10 years' experience as a manufacturer
3.CCC, ISO, BV certification
4.Perfect after-sale service
5.Export covering More than 50 countries and regions
6.Annual production value topped 1500, 000, 000 RMB (240, 000, 000 US dollars) per year
7.can produce water tank truck, fuel tank truck, bulk cement truck , LPG Tank, Garbage Truck, Tow Truck, Sewage Vacuum Truck, Aerial Platform, Concrete Mixer Truck, Road Sweeper Truck, Cargo Crane Truck, Firefighting Truck
Our main products
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
LPG tanker trailer brief Introduction
FAQ
1.Our price term: FOB Shanghai as common, other port is also acceptable.
2. Our Payment term: T/T, 30% deposit after order confirmation, 70% balance should be paid before delivery.
3. Delivery time: the delivery time is 20-30 days as common, the exact delivery time depends on the order and the current production condition.
Packaging and shipping
1, Packaging: nude or waxing;
2. Shipping: Ro-Ro ship or bulk ship according to the customer' order or requirement
If you are interested in this model, pls feel free to send inquiry, and we will always be glad to quote.
Technial parameters of 6x4 Dongfeng 375hp tractor truck
We have Technique Parameters table here,if it didn't show,you can check it by computer.
