Model NO.
LTB1204
Emission Standard
Standard
Fuel
Gas / Diesel
Service Life
6-10 Years
Size
Medium
Color
Customized
Condition
New
Overall Dimension(mm)
3875*1635*2145(mm)
Wheelbase(mm)
2010
Gear Box
F12/R12
Engine
4D32zt31/604
Steering System Type
All Hydraulic Steering
Pto Type
Rear-Mounted,Semi-Detached
Transport Package
Nuck Packing
Specification
3875*1635*2145(mm)
Trademark
LTMG
Origin
China
HS Code
842951000
Production Capacity
100units/Month
After-sales Service:
Service Points Overseas, Free Spare Parts
Warranty:
2000 Working Hours or One Year Whichever Comes Fir
Type:
Wheel Tractor
Usage:
Farm Tractor, Garden Tractor, Lawn Tractor
Certification:
ISO, CE
Drive Wheel:
4WD
Main Technical Parameters | ||
Model | LTB1204 | |
Type | 4X4 | |
Overall Dimension(mm) | Length | 4130 |
Width | 1720 | |
High | 2650 | |
Wheelbase(mm) | 2020 | |
Front Wheel Tread(mm) | 1353 | |
Rear Wheel Tread(mm) | 1352 | |
Min.Ground Clearance(mm) | 370 | |
Min.Turning Radius(m) | 4.8 | |
Min.Using Mass(kg) | 4525 | |
Gear Box | F12/R12 | |
Speed(km/h) | Going | 0.49-37.06 |
Retread | 4.72-13.83 | |
Engine | Model | 4C6-120C32 |
Rated Power(kw) | 88.3 | |
Rated Speed(r/min) | 2200 | |
Tyre Type | Front Tyre | 9.5-24 |
Rear Tyre | 14.9-30 | |
Steering System Type | All Hydraulic front Wheel Steering | |
Max.Lift-off Weight(KN) | ≥19.5 | |
PTO Type | Rear-mounted Semi-detached or Detach | |
PTO Speed(r/min) | 540/1000 | |
PTO Power(kw) | 71.2 | |
Roots in Control Mode | Height Adjustment,Floating Control | |
Max.Traction(KN) | 24.4 | |
Counterweight Quality(kg) | Front | 110 |
Rear | 200 | |
