Model NO.
CLW5252XGQ
Transmission Type
Manual
Payload
16tons
Fuel
Diesel
Drive Wheel
6×4
Horsepower
251-350hp
Condition
New
Engine Type
Wd615.47, 371HP
Extinguishant
Water, Foam and Dry Powder
Water Tank Capacity
5t, 5ton, 5tons, 5mt
Foam Tank Capacity
3ton, 3000kg, 3t
Dry Powder Tank Capacity
2tons, 2000kg, 2t, 2mt
Flow Rate of Fire Pump
60L/S 1.0MPa
Model of Fire Pump
CB20.10/30.60 Fire Pump
Type of Fire Pump
Low Pressure Centrifugal Pump
Flow Rate of Fire Monitor
60L/S 1.0MPa
Model of Fire Monitor
Pl48 Fire Monitor
Fire Monitor Range
Water More Than 65meters, Foam More Than 60meter
Suction Depth
Deeper Than 7m
Transport Package
Naked with Wax
Specification
10000L, 10cbm, 10000liters, 10m3
Trademark
CLW
Origin
Suizhou, China
HS Code
8705309000
Production Capacity
300 Units Per Month
After-sales Service:
with After Sales Service
Warranty:
Available
Type:
Tanker
Certification:
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Volume:
7001-10000L
Emission Standard:
Euro 2
HOWO Emergency Rescue 10Tons Water Dry Powder Foam Combination fire fighting truckDry powder Fire Fighting Truck ,which is also called water fire engine,water foam fire truck,fire fighting equipment, fire appliance truck, foam fire tanker, water foam pumper, light rescue apparatus, fire fighting vehicle, foam discharging truck, foam tanker fire truck is a special vehicle designed primarily for fire fighting operations and to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximumly.
dry powder fire fighting truck can be divided into several types:
1--According to vehicle size, there are mini fire fighting truck,light fire fighting truck,medium fire fighting truck, heavy-duty fire fighting truck.
2--According to chassis drive type, there are 4X2 or 6-wheel fire fighting truck, 6X4 or 10-wheel fire fighting truck, 8X4 12-wheel fire fighting truck and off-road type 4X4, 6X6 fire fighting truck for use.
3--According to chassis brand, there are ISUZU fire fighting truck, Dongfeng fire fighting truck, Foton fire fighting truck, FAW fight fighting truck, Shacman fire fighting truck, sinotruk fire fighting truck, Mercedes fire fighting truck, MAN fire fighting truck,Scania fire fighting truck and so on.
4--According to fire extinguishant,there are water tank fire fighting truck, dry powder fire fighting truck, water/foam fire fighting truck
5-There are also fire rescue truck with special purpose as follows,
--Foam supply fire truck;
--Compressed air supply fire fighting truck;
--Water tower fire truck ;
--Earthquake rescue fire truck;
Features of howo 10ton dry powder fire truck :
---- Optional for different siz,strong enough for all road conditions.
---- powderful engin; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure.
---- High quality fire pump
---- Massive, durable, long service life.
Spec. of HOWO Emergency Rescue 10Tons Water Dry Powder Foam Combination fire fighting truck
| Model | Parameters | others |
| Overall Dimension | 9965*2500*3750mm | |
| GVW | 26100kg | |
| Engine Model | WD615.47 | |
| Engine Power | 273kW | |
| Wheelbase | 4600+1350mm | |
| Driving Type | 6×4 | |
| Max.speed | 102km/h | |
| Emission Standard | 9726ml/kW | Euro4 |
| Fire pump rated flow | 60L/[email protected], 30L/[email protected] | Vacuum pump |
| water monitor rated flow | 48-64L/[email protected] (ajustable) | Straight stream/spray/mist spray |
| Water monitor range | Water range≥65m,Foam≥60m | |
| Passengers | 2+4 | |
| Approach angle | ≥16° | |
| Departure angle | ≥19° |
| Item Parameters | Parameters | others | |||
| 1 | Tank capacity | water | ≥5000 | ||
| Foam | ≥3000 | ||||
| Dry powder | ≥2000kg | ||||
| 2 | Fire pump model | CB20.10/30.60 | Shanghai rongshen | ||
| 3 | Fire pump performance | Pressure 1:1.0Mpa flow:60L/S Pressure 2: 2.0Mpa flow:30L/S | Use vacuum pump to priming water | ||
| 4 | the installation site of fire pump | rear | |||
| 5 | The quantity of fire pump water outlet | 6 | |||
| Dry powder tank pressure | 0.5Mpa~1.7Mpa | ||||
| 6 | Pressure gauge | 0-2.5 MPa | 2.6 level | ||
| 7 | Vacuum gauge | -0.1- -1 MPa | 2.6 level | ||
| 8 | Water monitor (PL48-64) | Injection pressure | water:≥65m Foam: ≥60m | Zhangqiu | |
| 1.0~1.2Mpa | |||||
| Depression/Elevation angle | -15-+75° | ||||
| Turning angle 340° | |||||
| 9 | Foam proportioner | 3%-5% | |||
| 10 | PTO Model | YTQ800F type full power sandwich , pneumatic | Sinotruk | ||
Equipment of howo fire fighting truck
| Item | Item | parameters | unit | quantity |
| 1 | sucking hose | Φ100×2m | piece | 4 |
| 2 | water filter | FJF100 | piece | 1 |
| 3 | water collector | FJ100 | piece | 1 |
| 4 | sucking pipe wrench | FS100 | piece | 2 |
| 5 | fire hydrant wrench | FB450 | piece | 1 |
| 6 | underground fire hydrantwrench | FBA800 | piece | 1 |
| 7 | 13 type water hose | ф13*65-20 | disc | 4 |
| 8 | 16 type water hose | ф16*65-20 | disc | 4 |
| 9 | Injecting Water hose | 13*65-5 | set | 2 |
| 10 | Adapter KJ65/80(hook inside) | Φ80mm×Φ65mm | set | 2 |
| 11 | Adapter | KT100/100 | set | 1 |
| 12 | straight stream nozzle | QZ19 | piece | 1 |
| 13 | Straight stream switch nozzle | QZG19 | piece | 1 |
| 14 | Multi-function nozzle | QLH19 | piece | 1 |
| 15 | water distributor | Φ80 inlet Φ65 outlet | piece | 1 |
| 16 | hose protector | FH80 | pair | 1 |
| 17 | Fire spade | 2# | Piece | 1 |
| 18 | Fire crowbar | GT06 | piece | 1 |
| 19 | hose hook | FG600 | piece | 4 |
| 20 | hose gaiter | FP470 | piece | 4 |
| 21 | fire axe | GFP890 | piece | 1 |
| 22 | Waist axe | GF325 | piece | 1 |
| 23 | Fire bucket | piece | 1 | |
| 24 | fire extinguisher | MFZ2 | piece | 1 |
| 25 | Original chassis tools and accessories | set | 1 |
Factory and production of fire fighting truck
