Model NO.
CLW
Transmission Type
Manual
Payload
4ton
Fuel
Diesel
Drive Wheel
4×2
Brand
Dongfeng
Models
Small
Usage
Dump, Swing Arm Type, Sealed, Hang Barrel Type, Arm Type, Compression Type, Eat Hutch Type
Condition
New
Wheel Base
3800 mm
Horsepower
120 HP
Logo
as Per Customer′s Request
Hopper Size
10 Cbm
Material
Carbon Steel
Engine
Chaochai
Tire
8.25 Nylon Tyre
Hooper Lifting
Hydraulic Lifting
Chassis Brand
Dongfeng, Foton, HOWO, Shacman, Isuzu
Body Thickness
4mm
User Manual
Yes
Transport Package
Naked, Waxed, Bulk Ship, RO-RO
Specification
6800x2000x3000mm
Trademark
CLW
Origin
Suizhou, China
HS Code
8705909090
Production Capacity
500 Unit/Month
After-sales Service:
Yes
Warranty:
One Year
Type:
Compactor
Certification:
ISO9000, CCC, TS16949, CE
Volume:
5cbm
Emission Standard:
Euro 3
16tons 18tons 20tons Hydraulic Hook Arm Garbage Truck Roll-off Arm Hook Lift 6x4 HOWO Pull arm hook Truck Telescopic Hooklift as Loading
Product Description
Swing Arm Garbage Truck is also called garbage collecting truck, garbage transport truck, mainly used in transporting kinds of garbage for municipal sanitatio ,large factories and mines ,etc, especially apply to transport household waste in residential area.
According to loading and unloading type, it is divided into the following categories: dump garbage truck, hook arm garbage truck, compactor garbage truck, swing arm garbage truck, self-loading garbage truck, sealed type garbage truck.
| Drive type | 4*2, New condition, LHD | ||
| Vehicle Main Dimensions | (L x W x H)mm | 6800×2000×3000 | |
| Wheel base (mm) | 3800 | ||
| Track front/rear mm | 2500/4500 | ||
| F/R Axle-Load | 5800/10000 kg, | ||
| Approach/departure angle | 20/13 | ||
| Curb weight | 5100 kg | ||
| GVW | 8275 kg | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | Chaochai,Brand,Diesel ENGINE | |
| Model | YC4FA120-33 | ||
| Type | 4 -stroke direct injection, 4cylinder in-line with water cooling, turbo-charging and inter-cooling; | ||
| Horse Power(HP) | 120 | ||
| Emission standard | Euro III | ||
| Gearbox | 6 forwards& 1 reverse | ||
| Clutch | Reinforced diaphragm clutch | ||
| Tire | 8.25 Nylon tyre,7 pc including 1 spare tire | ||
| Steering Gear | power steering, hydraulic steering with power assistance | ||
| Upper Body | |||
| Garbage Box Material | Carbon Steel Q235 | ||
| Garbage Box Volume | 5 CBM | ||
Remarks | 1. Color is optional 2.Customized LOGO painting as per customer request | ||
