We are the first level agency for SINOTRUK wholesale tuck series, we can supply HOWO tractor trucks, HOWO dump trucks, trailer truck, truck parts, agricultural machinery, agricultural machinery parts,HOWO concrete mixer trucks, special trucks and so on.we can supply trucks for our clients with good quality and competitive price, because we get directly support from the CNHTC factory.
| Chassis model | ZZ1257N4341W | Chassis brand | SINOTRUK |
| Overall dimensions | 9800X2496X3048mm | Wheel base | 4325+1350mm |
| Front/rear wheel track | 2022, 1830/1830mm | Front/rear suspension | 1500, 2600mm |
| Approach/departure angle | 16/15° | Maximum speed | 90km/h |
| Chassis Manufacturer | China National Heavy Duty Truck Group Co.,Ltd | ||
| Cab | Configuration | HW76 a row and a half deluxe cab(with sleeping berth), allowable 3 passengers | |
| Color | White, other color is optional | ||
| Engine | Model | WD615.69 | |
| Emission | Euro 3 | ||
| Type | 6 cylinders, in-line, 4-stroke, water cooled, turbo inter-cooling, direct injection, diesel engine | ||
| Rated power | 336hp, rated power speed 2200rpm | ||
| Displacement | 9726ml | ||
| Max.torque | 1350N.m | ||
| Bore x stroke | 126x130mm | ||
| Manufacturer | China National Heavy Duty Truck Group Co.,Ltd | ||
| Tire | Size | 12R22.5 tubeless tire | |
| Number | 10+1 nos | ||
| Clutch | φ430 diaphragm clutch | ||
| Fuel tank | 400L iron oil tank | ||
| Front axle | HF 7 tons | ||
| Rear axle | ST 16 tons | ||
| Drive form | 6X4 | ||
| Suspension | Multi leaf springs | ||
| Rated voltage | 24V, DC | ||
| Transmissions | gearbox HW19710, 10 speed forward 2 reverse. | ||
| Steering device | Power assisted steering | ||
| Steering wheel | Left hand drive | ||
| If there is a slight change in the chassis parameters above, please take the actual product as the standard | |||
Refuse compactor structure parameters | |
Equipment | |
Structure | Body, sub frame, lifting rear part, the loading device, the pushing-out plate, hydraulic and electric systems |
Loading capacity | 18m3 |
System of loading | Mechanized, rear loading |
Modes of the pressing | Manual,semi-automatic,automatic,lifting rear part operation manual,loading,pushing,pressing, pushing out automatic |
Body | |
Version | All-metal |
Shape | arc-shaped |
Sidewalls | Sheet carbon steel (thickness: 4 mm) |
Bottom | Sheet carbon steel (thickness: 4 mm) |
Roof | Sheet carbon steel (thickness: 4 mm) |
Front frame | Sheet carbonaceous steel (thickness: 5 mm) |
Rear frame | n-shaped profile from sheet carbon steel (thickness:5 mm) |
Basis | 120x120mm (thickness: 5 mm) |
Loading bunker | |
Loading bunker | All-metal with sidewalls and a loading ladle |
Volume | 1.8 m3 |
Sidewalls | Sheet carbon steel (thickness: 4 mm) |
Ladle floor material | Sheet carbon steel (thickness: 4 mm) |
Liquid drain | Drainage channel,sewage tank |
Working zone Lighting | 2 lamps |
Mechanism of raising | Two hydraulic cylinders |
Ensuring tightness | Between the body and lifting back part in the lower part profile acid-proof rubber is used. |
Pressing system | |
Features | Control mode diversification,bidirectional compression |
Pressure | 16Mpa |
Compaction ratio | 3.0:1 |
Loading cycle | 25-30 second |
Unloading cycle | 15-20 second |
pressing mechanism | The giving plate and hinge related pressing plate moving on two directing bars |
Pressing mode | Automatic pressing (1 full cycle and continuous pressing) and controlling of each cycle of pressing separately |
Control of pressing | Control from the external panel on the bunker |
Lifting rear part | |
Mechanism of lifting | Two hydraulic cylinders |
Function description | Suitable for various rubbish bins |
Others | |
Color and Logo | Optional |
Standard configuration | Chassis,arc-shaped body,sub frame,rear lifting part,loading bunker,pushing-out plate,hydraulic system,pressing system,sewage tank,climbing ladder,pneumatic control. |
Selective configuration | PLC electric automatic control,multifunctional rear lifting part,rear handrail and footplate,other shapes of body,rear swing arm,and etc. |
Our company
Jinan Quanyu Import and Export Co., Ltd. is one of the main exporters of Chinese trucks which is authorized by Ministry of Commerce, and our company belong to SINOTRUK sales department and we have specialized in sinotruk trucks and spare parts for many years.The famous brand of sinotruk are HOWO series,HOWO A7 series,HOHAN series.We can supply tractor truck,dump truck,cargo truck,concrete mixer truck,fire tanker truck,water truck,fuel tank truck,bulk cement truck,sewage suction truck and also different types of semi trailers.
SINOTRUK is located in Jinan city and was founed in 1956.It once manufactured china's first heavy duty truck.In 1960,sinotruk introduced the steyr technology using on engine and axle from Austria.Later,sinotruk established cooperation with German man group and wobaco company.Today,sinotruk has developed into china's largest heavy duty truck manufacturing base and made significant contributions to the development of china's heavy duty truck industry and national economic growth.
We have not only the certificate and license of truck export and also strict quality management, fast and convenient channel of goods delivery, strict examination in quality and quantity of products, professional packing, professional and reliable loading goods, on-time delivery and competitive prices. If you want to buy these products, please contact us.
We sincerely hope to cooperate with you to expand market in your country!
Certificates
Prouducts Quality
1.Quality is life and our company is confident in the superior quality of our products and is the most effective salesman.
2. Our company has advanced production management and research and development technology, and continues to carry out technical innovation.
3. Our company introduced automatic integrated molding production equipment, which greatly reduced production process and ensured product quality stability.
4. Our company has its own set of testing methods and standards.
