Model NO.
ZZ1047D3414C145
Bearing Capacity
Small
Car Type
Van
Condition
New
Transport Package
Nude
Specification
6000*2200*3200mm
Trademark
SINOTRUK HOWO
Origin
Shandong, China
HS Code
8705909990
Production Capacity
500 Units/Month
SINOTRUK Howo Refrigerted Truck 4x2 5 Ton Payload Refrigerator Truck
Refrigerator truck is mainly consisting of chassis, heat insulation box body, refrigeration unit, temperature recorders in the carriage. For special purpose, optional parts including meat hook, aluminum alloy rail, ventilation channel etc. According to the different chassis model, we have mini type, middle-sized, large-scale etc. refrigerator trucks for your choice with different brands.
Product Parameters
Competitive Advantage
Refrigerator truck is mainly consisting of chassis, heat insulation box body, refrigeration unit, temperature recorders in the carriage. For special purpose, optional parts including meat hook, aluminum alloy rail, ventilation channel etc. According to the different chassis model, we have mini type, middle-sized, large-scale etc. refrigerator trucks for your choice with different brands.
Product Parameters
| Chassis Description | |
| Cab | Single row cab with power steering, electronic flame-out, A/C |
| Color | Optional |
| Allowable person in cab | 2/3 |
| Wheel base (mm) | 3360 |
| Number of axles | 2 |
| Front axle | 2000 |
| Rear axle | 4000 |
| Traction system | 4×2 |
| Tire specification | 7.00R16 |
| Tire quantity | 6+1 |
| Engine Description | |
| Fuel Type | Diesel |
| Engine model | 4KH1CN5HS |
| Emission standard | Euro 5 |
| Exhaust | 2999ml |
| Horse power | 130hp |
| Up-parts Description | |
| Van box dimension(mm) | 4100×2100×2050 |
| Material of van box | Glass fiber reinforced plastics |
| Insulation thickness(mm) | 80 |
| Refrigeration units | 550 |
| Type | Independent unit |
| Temperature setting range | -25ºC-+30ºC |
| Refrigerant Type | R404A |
| Refrigerant Filling quantity (kg) | 1.8 |
| Compressor Model | TK16 |
| Refrigerating Capacity (w) mbient temperature 30ºC (A.T.P.) | 0ºC 4050/ -25ºC 2300 |
- The "sandwich" board bonding type assembled by pieces is currently adopted by large domestic refrigerating truck manufacturers, and the refrigerating truck produced by this technology has high heat insulation performance.
- Refrigerated car body structure: Polyester wet plate making process and glass fiber reinforced stainless steel column frame structure, using the most advanced fifth-generation fully enclosed polyurethane plate bonding method in the world.
- The material of the panel: the inner and outer wall panels are made of domestic high-quality mechanism 2.2mm FRP; the intermediate insulation material is made of thick imported polyurethane; the thickness of the car body is 80mm; the thickness of the door is 80mm; the overall aluminum plate on the bottom plate, the color plate below, the imported polyurethane.
- Accessories: 2.5mm aluminum alloy edging around the car, stainless steel wrap angle, stainless steel door lock, anti-collision rubber 4, stainless steel door frame, stainless steel hinge, energy saving lighting inside the box.
- Refrigeration unit: The well-known domestic brand of the refrigeration unit American Carrier or Thermoking overhead unit, the temperature of the car is 0 to 5 degrees and 18 degrees.
