Howo 10cbm Sewer/Sewage/Sewerage/Septic Suction tanker Truck 10000liters 10m3 Vacuum Cessipit Emptier
Description
--Howo sewage truck (also called vacuum truck,vacuum tanker,sucker truck,sewer sucker,hydro-vac,vac-trucks,exhauster truck,sewer vacuum truck,septic suction truck,sewage vacuum truck,sewer cleaning truck,sewage tanker,cessipit emptier,gully emptier,drainage suction truck,vacuum truck,sewage truck,waste vacuum truck,drainage treatment truck) is one of the new sanitation type vehicle to collect,clean and transport sludge, sewage to avoid secondary pollution.
Howo sewage truck is with advantage of self-suction from discharge, fast working speed, large capacity, convenient transportation suitable for the collection and transport of feces, mud, crude oil and other liquid materials.
Also with advantage of large suction force and long suction distance, especially suitable for the suction, delivery and discharge of silt in the sewer, especially for the suction of the sewer mud, stones, bricks and other large objects.
Feature
--Howo sewage truck tanker material optional for carbon steel or stainless steel 304;
--Tanker thickness 6~8mm,endplate thickness 8mm and baffle 5mm;
--Sewage suction pump is optional for chinese brand single weilong pump,water ring suction pump,Italy brand BP,Jurop,Keiser Moro imported brand;
--Suction speed less than 10min and and discharge speed less than 8 min;
--horizontal suction distance: within 80 meters;
--Vertical suction depth:within 9 meters;
--Heavy Duty Howo truck chassis;
| Complete Vehicle Parameter | |
| Vehicle | HOWO sewage suction truck |
| Overall dimension (mm) | 9000×2500×3300 |
| Sewage tank (m3) | 10m3/12m3 septic tanker truck |
| Gross vehicle weight (kg) | Appro×16000 |
| Curb weight (kg) | Appro×6000 |
| Payload (kg) | Appro×10000 |
| Wheel base (mm) | 4600 |
| Max speed (km/h) | 90 |
| Chassis Parameter | |
| Cabin | Flat top cabin,a sleeper,power steering, air conditioner, 3 passengers,left hand drive,with Air Conditioner |
| Drive form | 4X2 |
| Engine | Brand: SINOTRUCK |
| Model: WD615.69,336HP/290HP/266HP | |
| Type: diesel, turbocharged, 6 cylinder. | |
| Displacement: 9726ml | |
| Emission standard: Euro 2 | |
| Transmission | 10 forward,2 reverse, manual operated |
| Tire model | 12R22.5 |
| No.of tires | 6 pcs, with 1pc spare tire |
| Superstructure Parameter | |
| Characteristic | 1. Sewage tank volume 10000 liter/12000liters Septic tanker truck |
| 2. Sewage tank material is carbon steel,thickness 5mm. | |
| 3. Sewage suction pipe 1pcs, length 7m. | |
| 4. Hydraulic lifting sewage tank,rear cover can open. | |
| 5. Equipped with PTO. | |
| 6. Equipped with vacuum pump. | |
| 7. Equipped with oil water separator, overflow valve,looking sewage window, self flow exit,hand washing device. | |
| Performance | (1) Vertical suction ≥ 7m. |
| (2) Pumping speed : 45L/s. | |
| (3) Intake and exhaust diameter: 50mm. | |
| (4) Full tank pumping time ≤ 5min. | |
| (5) Sewage tank emptying time ≤ 4min. | |
Before purchasing:
1-Quick reply on customers' inquiry;
2-Professional suggestion on truck choice according to different countries.
3-Details quotation with spec.and reasonable price.
4-Welcome to visit our company before purchasing.
After purchasing:
1-Production pictures and video updated every week.
2-Customer can visit factory after truck completion or arrange third party inspection.
After-sales service:
1-English Operation Video
2-Free operation and technical train at factory but not include accommodation
3-Spare parts supplied at factory price whenever needed.
4-Engineers can be sent to your country and offer local engineering support and train.
Q1: What kinds of howo sewer vacuum truck I can order from your company?
A: We can supply normal sewege suction truck and high pressure sewer flushing and sewage suction truck, the difference between above two kinds of sewer cleaning truck are water tank and high pressure water pump. Basically speaking, we can supply 5CBM to 35CBM sewer cleaning truck as per our customer's request. Pls contact with us for more technical details discussion.
Q2: What is your production standard of sewer vacuum truck? Whether your sewer vacuum truck can export to USA, Canada and Europen countries?
A: Our CBU sewer vacuum truck is produced as per China GB local standard; We can export super structure to those market, we ever exported 50 units sewage suction truck's super structure and 20 units sewage suction sewage trailer to Australia market in the past two years.
Q3: Can we adopts International brand sewage pump for sewage suction truck?
A: Sure, we already cooperated with Italy brand BP,Jurop,Keiser Moro imported brand
Q5: Except for howo sewer suction truck,what else of other truck brand you can supply?
A: we can supply ISUZU sewer suction truck,FAW septic vacuum truck,Dongfeng sewage cleaning truck,Shacman Vacuum Cessipit Emptier,Foton drainage vacuum truck.
Q5: What about warranty of howo sewage suction truck?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q6: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
Q7: Except for vacuum sewer truck,what other trucks can you supply?
A: We can supply various types of trucks,mian types are as follows,
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
