Model NO.
BJ1123V
Drive Wheel
4x2
Hoesrpower
150HP
Condition
New
Gvw
18000kg
Chassis Brand
Foton
Capacity
10cbm
Pump Flux
68(L/S)
Chassis Model
Bj1123V
Tire Specification
8.25-20
Engine Model
Ca4df3-15e3
Number of Gears
6-Speed
Color
Customization
Steering
LHD
Cab
One and Half Row
Transport Package
After Waxing by Container, RO-RO, Bulk Freighter
Specification
8300*2500*3500mm
Trademark
SUNY
Origin
China
HS Code
081995491
Production Capacity
500units/Year
Certification:
ISO9000, CCC, CE
Emission Standard:
Euro 3
Payload:
1-4t
Transmission Type:
Manual
Fuel:
Diesel
Tank Volume:
8000-12000L
FOTON ETX 10cbm vacuum sewage suction truck with cheaper price
Vacuum sewage suction truck is used for removing and transporting sand, stones, grease, sludge and other debris from sewage pipelines and / or sanitary sewer by vacuum suction pump.
It also could provide efficient solution to industrial vacuum requirement . Hydraulic system and pneumatic components could be added to fulfill the requirements of specific operations.
Hubei Suny Automobile and Machinery Co., Ltd is the professional company which is abide by the business integrity and
quality win for the purpose of customers' intentions.
We aimed to be the access for you in getting the most suitable Chinese heavy-duty and special purposed trucks, which
are widely used in environmental protection, city construction, transportation and many other fields.
Over the 10 years experience in manufacturing, we have established long-term and stable relationship with the customers
all over the world and Chinese main manufactures.
With the years of experiences in exporting, we have got the trust from lots of clients who come from different districts, such
as the whole Africa, South America, Southeast Asia, Mid-east, etc. We will keep striving to improving our profession and
efficiency, meanwhile continuously promoting our service for all the customers all over the world!
Our product: sanitary truck, different kinds of garbage trucks, fire fighting truck, road wrecker truck, bitumen distributor truck, different kinds of van trucks, dump truck, concrete mixer truck, bulk cement truck, truck with crane, different kinds of semi trailers for transporting the fuel, chemical, bulk cement, containers, LPG, etc.
Our cooperation brand:
Our office and workshop:
Customers' visiting to us:
Our team abroad:
Our shipment:
It also could provide efficient solution to industrial vacuum requirement . Hydraulic system and pneumatic components could be added to fulfill the requirements of specific operations.
| Vehicle Description | |
| Overall dimensions | 8300*2500*3500mm |
| GVW | 18000kg |
| Mass in working order | 6900kg |
| Chassis brand | FOTON |
| Traction type | 4*2 |
| Tanker Description | ||
| Tanker | Capacity | 10000 Liters |
| Material | 6mm thickness, high quality carbon steel | |
| Structure | Welding, vacuum tank, Cylindrical | |
| pump | Type | Double vacuum pump |
| Flux | 68(L/S) | |
| Rating speed | 800~1000(r/min) | |
| Shaft power | 5(kw) | |
| Features | Low speed, low fuel consumption, low noise, high vacuum, high efficiency | |
| Manufacture | Hangzhou WEILONG Pump Co., Ltd. | |
| Pipe | Suction and discharge pipe | |
| Special function | Suction time ≤ 5min, effective suction range ≥ 8, Max vacuum degree ≤ 15 Kpa, dump angle ≥ 45 | |
| Standard configuration | Equipped with Inspect window,discharge valve,cleaning apparatus,5 meter long suction pipe,oil-water separators, overflow valve,etc. Cylinder vacuum tank can be lifted hydraulically to 40-45 degree. Rear door can be opened and closed hydraulically. | |
| Optional configuration | Tanker material: stainless steel. Vacuum pump : Italy or Spain vacuum pumps. Anti-rust coating inside tank | |
| Chassis Description | ||
| Chassis model | BJ1123V | |
| Steering | LHD/RHD | |
| Cab | ETX ,one and half row, with A/C | |
| Wheelbase | 5000mm | |
| Tire specification | 8.25-20 | |
| Tire quantity | 6 tires and 1 spare tire | |
| Engine | Engine model | CA4DF3-15E3 |
| Emission level | EURO 3 | |
| Displacement/output | 4700ml/110kw | |
| Horse power | 150HP | |
| Gear box | Model | DC6J70T |
| Number of gears | 6-speed | |
| Brake system | Air break | |
| Axle | Front | 4.2T |
| Rear | 7.8T | |
| Fuel tanker | Type | Aluminium alloy |
| Capacity | 200L | |
