Model NO.
SJCH500A
Power
24.4kw
Specification
3865*1150*1990mm
Trademark
XCMG
Origin
Xuzhou, Jiangsu, China
Production Capacity
1000/Year
XCMG Cleaning Equipment Floor Sweeper machine SJCH500A.
1. An advanced and efficient dusting method: The pulse dusting method is adopted, with high dusting efficiency.
2. Extensive auxiliary functions: Humanization design of radio and tape player, air conditioner, phone charger and reversing camera.
3. A liquid crystal display is provided for all-round display of the street sweeper information.
4. Swinging and lifting of the sweeper is operated with an operating handle. It is simple and intuitive.
5. A simple one-key operating system: It is simple and easy to learn. It can be operated by ordinary sanitation workers.
6. An advanced battery management system: Monitor the status of every battery in real time; help the driver to accurately master the working time, give better protection to the battery pack, and make it more convenient for battery maintenance.
7. Convenient wireless operation and control: Tip-over and resetting of the dustbin and opening/closing of the dustbin door can be wireless controlled. It is safe and sanitary.
Items | Unit | Number |
Engine model | - | Perkins 403D-15 |
Engine power rating | kW | 24.4 |
Engine rated speed | r/min | 2800 |
Engine idle speed | r/min | 800 |
Maximum speed | km/h | 20 |
Maximum astern speed | km/h | 10 |
Capable of climbing with slope | % | 22 |
Fuel tank capacity | L | 60 |
Wheelbase | mm | 1250 |
Turning radius (outside) | mm | 1880 |
Minimum ground clearance | mm | 140 |
Front overhang | mm | 810 |
Rear overhang | mm | 560 |
Approach angle | ° | 20.7 |
Departure angle | ° | 27.7 |
Brush diameters | mm | 600 |
Maximum volume of dustbin | L | 500 |
Bin effective volume | L | 230 |
Bin unloading height | mm | 1380 |
Water tank volume | L | 120 |
Host suction diameter | mm | 150 |
Handheld suction diameter | mm | 120 |
Maximum sweeping speed | km/h | 6 |
Curb weight | kg | 1250 |
GVW | kg | 1800 |
Overall dimensions | mm | 3865×1150×1990 |
Hydraulic tank capacity | L | 20 |
Operating system voltage | V | 24 |
