Model NO.
CLW5063GB
Fuel
Diesel
Drive Wheel
4×2
Engine Capacity
＜4L
Condition
New
Rotation Angle of Dust Fighter Sprayer
360 Degree
Full Tank Suction Time
<15 Minutes
Suction Height
>7m
Sprinkling Width
14m
Dust Fighter Sprayer
30m
Tank Material
Carbon Steel
Tank Thickness
4mm
Chassis Brand
Dongfeng, Isuzu, Foton, etc.
Drive Type
4*2 / 6 Wheels
Warranty
1 Year
Delivery Time
30 Days
Gearbox
5 Forward & 1 Reverse
Fuel Type
Diesel
Transport Package
Naked, RO-RO, Bulk
Specification
5500*1960*2880mm
Trademark
CLW
Origin
Suizhou, China
HS Code
8705309000
Production Capacity
500 Units/Month
Volume:
3m3, 4m3, 5m3, 6m3, 8m3, 10m3, 12m3
Certification:
ISO9000, CCC, EPA, EEC, CE
Emission Standard:
Euro 5
Sprinkling Area:
12 - 16m
Transmission Type:
Manual
Payload:
3ton, 4ton, 5ton, 6ton, 8ton, 10ton, 12ton
Forland 4tons 5tons Sprinkler Water Tanker Truck Dust Suppression Gog Gun
Product Advantages:
1. Factory export department directly sale.
2. Export experience more than 12 years.
3. Cheap / competitive price, high quality, you get more than your paid.
4. With CCC, ISO, BV approved.
5. The heart of the service, rational design.
Working scene:
The CLW group, which was appointed by the Development and Reform Committee of China. CLW group is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.
Products Catalog:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Product Advantages:
1. Factory export department directly sale.
2. Export experience more than 12 years.
3. Cheap / competitive price, high quality, you get more than your paid.
4. With CCC, ISO, BV approved.
5. The heart of the service, rational design.
| Chassis Specification | ||||
| Item No. | Parameters | |||
| Chassis Brand | Forland | Overall Dimension | 5500×1960×2880mm | |
| Gross Vehicle Weight | 6260kg | Curb Weight | 2270 kg | |
| Loading Weight | 4000 Kg | Wheel Base | 2850 mm | |
| Cabin | Single, Left Hand Driving | |||
| Engine | 88HP, EURO V | |||
| Overhang( Front/Rear) | 1100/1510(mm) | |||
| Fuel type | Diesel | |||
| Axle load | 1600/2700(kg) | |||
| Angle(Approach/departure) | 16/22(°) | |||
| Transmission/Gearbox | 5 Forward & 1 Reverse Gear | |||
| Brake System | Pneumatic | |||
| Steering Gear | Power Assistant | |||
| Tire | 6.50R16LT, 6 Pieces with 1 spare tire | |||
| Maximum speed | 105(km/h) | |||
| Superstructure | ||||
| Water Tanker | Tank Volume | 4000 Liters / 4m3 | ||
| Tank Material | 4mm Q235B Carbon Steel | |||
| Sprinkling System: | Suction height of Truck Pump | >7m | ||
| Full Tank Suction Time | <15 minutes | |||
| Sprinkling width of front/rear/side Sprinkler | ≥14m | |||
| Dust Fighter Sprayer | 30m | |||
| Rotation angle of Dust Fighter Sprayer | ±360° | |||
| Generator Power | 6.5kw | |||
| Remarks | Other Parts: Self-flow valve 1pc; Fire joint 1pc; Water pipe 2pcs | |||
