Model | CDD-II -500 | CDD-II -800 |
Order Number | 5.11001 | 5.11002 |
Capacity (kg) | 500 | 800 |
Fork lift height(mm) | 3500 | 3500 |
Fork min height (mm) | 540 | 540 |
Fork max.height(mm) | 4000 | 4000 |
Wheel type | PU | PU |
Clamp method | Electric Hydraulic | Electric Hydraulic |
Bale size (mm) | 1150X1200X800 | 1150X1200X800 |
Weight (Kg) | 620 | 860 |
Over size(mm)L*W*H | 2245*1429*2150 | 2245*1429*2150 |
Channel request(mm) | 1500Turn | 1500Turn |
Forward and Back request | 3000mm | 3000mm |
1:Use special vertical clamp jaws, suitable for paper shredder industry,
2:The clamp jaws adjustments are automatic, could custom produce according to what the clients'need.
3:Come with AC drive motor, control more precise, run more smoothly, battery long service lift
4:Using the latest electronic steering handle, can effectively reduce the strength and intensity of work
required. Greatly reduce to the required strength, to improve driving stability and comfort.
5:Frame structure is strong and durable, ensure that goods fork easily handle heavy goods
6:The timer and electricity meter displays electricity usage at any time, convenient to inform the operator charge in time.
