Model NO.
WMF-1000
Load center
600mm
Lift height
1600mm
Condition
New
Mass
680kg
Payload
<1400kg
Fork Size(L*W*H)
1565*882*2040mm
Navigation
LiDAR SLAM
Minimum Turning Radius
1130mm
Minimum Ground Clearance
30mm
Travel Speed(with/Without Load)
5/6km/H
Lifting Speed(with/Without Load)
115/170mm/S
Battery Type
Lithium Iron Phosphate
Battery Voltage/Rated Capacity(5h)
48V/180ah
Specification
1565*882*2040mm
Trademark
Wellwit
Origin
Shenzhen
After-sales Service:
One Year
Warranty:
One Year
Type:
Electric Forklift
Power:
AC Motor
Load Capacity:
1T - 5T
Fuel:
Electric
Notes:1. The road surface shall be flat, clean and free from obvious undulation. Slope 5% = arctan(0.05)≈ 2.8°. The robot shall not stop or turn at the ramp, step or gap, and can only pass through the ramp, step or gap perpendicular to the ramp, step or gap quickly.
2. The positioning accuracy is affected by environment, ground,etc. Please refer to the interpretation of positioning accuracy in the final technical agreement.
3. Basic functions include but are not limited to map editing, model editing, positioning module, navigation module and APl interface.
4. lt needs to be used with a special automatic charging pile.
5. Special camera is required to realize this function.
6. 3D camera is required to realize this function.
7. WMF1000 is only designed for indoor transportation, not recommended for outdoor environment.
Shenzhen WellWit Robotics Co., Ltd was established in Shenzhen in March 2015, our company focuses on research and development of mobile robot. The R&D team consists of members who experienced in field of robot, embedded hardware, software, algorithms, artificial intelligence, etc. Currently, products for sale including moving robot, sorting robot, Auto-forklift, etc. Navigation method we provide including QR code navigation, LiDAR SLAM navigation, Visual SLAM Navigation, RTK navigation.
We focus on providing custom logistic robots for the integrators who focus on Intelligent Logistics and Intelligent Factory, and provide AGV&AMR with ODM/OEM service for global clients.
