Model NO.
LG25DT
Fuel
Diesel
Load center
500mm
Lift height
3000~5000mm
Condition
New
Ratedcapacity
3500kg
Transport Package
Nude
Specification
3.5Ton
Trademark
SINOMADA
Origin
China
HS Code
8708991000
Production Capacity
50/Month
After-sales Service:
1 Year
Warranty:
1 Year
Cab Location:
Adjustable
Type:
Diesel Forklift
Power:
Diesel Engine
Load Capacity:
1T - 5T
New FD35T Lonking Brand 3.5ton Diesel Forklift Truck For Lifting goods on sale
Contact
Terry
Main Features
* Improved driver's view
Standard configuration of wide view mast, compact structure of mast and tube pulley block;
Overhead guard with large arc and grid tray with optimized angle enlarge driver's upper view.
* Improved operation comfort
Mast buffer, rear axle buffer and rear extension type valve operation knob increase operating comfort effectively;
Ratchet type hand brake facilitates comfort driving;
* Improved driver's view
Standard configuration of wide view mast, compact structure of mast and tube pulley block;
Overhead guard with large arc and grid tray with optimized angle enlarge driver's upper view.
* Improved operation comfort
Mast buffer, rear axle buffer and rear extension type valve operation knob increase operating comfort effectively;
Ratchet type hand brake facilitates comfort driving;
| MODEL | FD35(T) |
|---|---|
| Powertype | Diesel |
| Ratedcapacity(Kg) | 3500 |
| JLoadcentre(mm) | 500 |
| h1STDMaxliftingheight(mm) | 3000 |
| h3Freeliftingheight(mm) | 170 |
| L5*W*TSTDForksize(mm) | 1070×125×50 |
| Masttiltangle(deg) | 6/12 |
| L3Frontoverhang(mm) | 498 |
| L4Rearoverhang(mm) | 600 |
| R1Min.turningradius(mm) | 2490 |
| Min.width for pallets 1,000×1,200 crossways (L×W)(mm) | 4200 |
| Speed(load/unload) | |
| Max.travelingspeed(km/h) | 20 |
| Max,liftingspeed(mm/s)(load/unload) | 380/400 |
| Max.gradient(%) | 20 |
| STD Dead weight(kg) | 4650 |
| S/PTread(frnt/rear)(mm) | 1000/980 |
| L2Axledistance(mm) | 1700 |
| Min.groundclearance | |
| m2Mast(mm) | 130 |
| m1Frame(mm) | 160 |
