Model NO.
CLW5089ACG
Bearing Capacity
Small
Car Type
Van
Condition
New
Wheel Base
3360 mm
Tire
7.00-16
Insulating Layer
8cm Polyurethane Foam
Applicable Temperature
-18~0 Degree
Warranty
1 Year
Logo
as Per Customer′s Request
Gearbox
5 Forward & 1 Reverse
Material
Fiberglass
Transport Package
Nude, Container, RO-RO, Bulk
Specification
5995x2320x3350 mm
Trademark
CLW
Origin
Suizhou, China
HS Code
8705909090
Production Capacity
500 Units Per Month
Certification:
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Payload:
1.5ton
Emission Standard:
Euro 2
Transmission Type:
Manual
Horsepower:
129HP
Fuel:
Diesel
2t 3t 4t Foton Refrigerated Ice Cream/Meat/Fruit/Vegetable/Food/Vaccine Freezer Transport Refrigerator Truck
Product Description
1. Purpose of the truck : transport frozen fish, meat, fresh vegetables and vaccinum, etc.
2. Main parts of the truck: Refrigerating unit and control system.
3. Features of the truck: International chassis brands and refrigerating unit brands for optional.
Product Specification
Product Description
1. Purpose of the truck : transport frozen fish, meat, fresh vegetables and vaccinum, etc.
2. Main parts of the truck: Refrigerating unit and control system.
3. Features of the truck: International chassis brands and refrigerating unit brands for optional.
Product Specification
| General Technical Parameters | ||||
| Overall Dimension | 5995×2320×3350(mm) | Gross Vehicle Weight | 4495 (Kg) | |
| Curb Weight | 2805 (Kg) | Loading Weight | 1495(Kg) | |
| Chassis Specification | ||||
| Chassis parameters | Chassis Brand | Foton | ||
| Cabin | Single, Left Hand Driving, with A/C | |||
| Engine | Model | 4 Cylinders | ||
| Power | 96 KW/130 HP | |||
| Emission standard | EURO II | |||
| Displacement | 2780 ml | |||
| Fuel type | Diesel | |||
| Gearbox | 5 Forward & 1 Reverse Gear | |||
| Front and Rear Axle load | 2.5T/4.8T | |||
| Wheel base | 3360(mm) | |||
| Brake System | Oil brake | |||
| Steering Gear | Power Assistant | |||
| Tire | 7.00-16, 6 Pieces with 1 Spare Tire | |||
| Maximum speed | 90 (km/h) | |||
| Superstructure | ||||
| Van | Box size | 4085×2100×2100(mm) | ||
| Material | Fiberglass | |||
| Insulating Layer | 8cm Polyurethane Foam | |||
| Refrigerator | Brand | Carrier | ||
| Applicable temperature (ºC) | -18~0 | |||
| Remarks | Part Optional: Ventilation slot Hook External power supply Side door | |||
