Safe & Durable
• Electronic AC traction motor and pump control with self-protection features that do not require any maintenance.
• Motors are equipped with temperature and speed sensors to prevent accidental damage.
• Closed-loop speed control with standard power selection switch (crawl) that ensures safety and power saving.
• Automatic ramp parking with empty or full load.
Energy & Efficient
• Interactive LCD meter that can customize driving and lifting performance, and monitor the operating conditionsof the motors to provide work time and fault code.
• Closed-loop lifting speed control that ensures accurate and comfortable lifting control.
• CAN electrical bus control offers fast and accurate signal transmission.
• Sufficient climbing power that can increase overall speed by 20%.
Smooth & Quiet
• Excellent handling performance that ensures stable and fast acceleration during operation.
• Load sensing and single pump bypass technologies that reduce steering noise significantly.
• Low-noise toothed pump that reduces operating noise significantly.
• 30% energy recovery while braking to provide more power for the battery.Specifications Unit FB25H-B1 FB25H-J1 FB25H-J1 Characteristics Power battery battery lithium
battery
Capacity kg 2500 2500 2500 Center of load mm 500 500 500 Lifting height mm 3000 3000 3000 Free lifting height mm 145 145 145 Forks L×W×H mm 1070×
122
×40
1070
×122
×40
1070
×122
×40
Mast tilt angle
Forward/Backward
. 6/8 6/8 6/8 Min.turning radius mm 2020 2020 2020 Min right angle
stacking width
mm 3924 3924 3924 Min.ground clearance
(mast)
mm 110 110 110 Overhead guard height mm 2196 2196 2196 Front overhang mm 434 434 434 Rear overhang mm 312 312 312 Perf Max.traveling speed
(loaded)
km/h 14.5 14.5 14.5 Max.lifting speed
(loaded/unloaded)
mm/s 260/
490
330
/510
330
/510
Gradeability % 18 18 18 Dimensions Overall length
(without fork)
mm 3367 3367 3367 Overall width mm 1186 1186 1186 Mast lowered height mm 1990 1990 1990 Mast extended height mm 4040 4040 4040 Chassis Tire Front 23x9-
10-
16PR
23x9-
10-
16PR
23x9
-10-
16PR
Rear 18x7-8-14PR 18x7-8-14PR 18x7
-8-14PR
Wheelbase mm 1550 1550 1550 Tread width Front/Rear mm 961/950 961/950 961/950 Curb weight None-load kg 4250 4350 4350 Powertrain Battery Voltage/
Capacity
V/Ah 600 48/700 630 Battery model 5PzS600H 5PzS700H D-630 Motor Traveling KW YQD11.5-4-6190 YQD11.5-4-6190 XYQ-11-6H Auxiliary KW XQD-10-3S YDB15-4HL XYQD-14-1H Rated power Traveling kw 11.5 11.5 11 Auxiliary kw 10 15 14 Working
pressure
Mpa 17.5 17.5 17.5
