Product Description
Products Description
High Quality horizontal directional drilling XZ3600 With High Dumping
2.Rack and pinion sliding, to ensure the stability of the carriage and the reliability of drive operational. Carriage floating,floating vise patented technology can greatly protect the drill pipe thread, increase the service life of the drill pipe.
3.High-speed sliding systems, variable motor to achieve high and low carriage sliding change, increasing the ability to adapt the drilling rig working conditions, improve the efficiency of the drilling rig construction.
4.Stable chassis support, using the classic H-beam structure, high quality rubber track, breaststroke leg structure, provide a strong guarantee for the stability of the whole construction.
5.lt adopts high-low-speed push-pull and rotation system in which the plunger-type variable displacement motor can achieve high and low speed push-pull of the power head,improving the ability to adapt to various working condition sand construction efficiency of the drilling rig.
Product Paramenters
Engine | Model | QSL8.9-C360 |
Power rating (kw/r/min) | 2*264/2100 | |
Thrust-pull | Max pull / thrust force (KN) | 3600 |
Max pull / thrust speed (m/min) | 30 | |
Rotation | Torque (n.m) | 120000 |
Max spindle speed (r/min) | 76 | |
Mud pump | Max flow rate (L/min) | External connection |
Max pressure (Mpa) | 20 | |
Pipe | Diameter*length (mm*m) | φ140/φ168*9.6 |
Loader Crane | Lifting weight (t) | 3.2 |
Loading capacity (t.m) | 6.4 | |
Max inclination angle (° ) | 16 | |
Max backreamer diameter (mm) | φ1600 | |
Weight (t) | 48 | |
Dimension (mm) | 17500*3200*3550 | |
