The body is small and exquisite, with good passing performance, and it is very convenient to handle the pile hole construction in the narrow site. It can be called the elf on the construction site.The whole machine is transported with drill pipe, which is convenient and quick to transfer.
Strengthen the chassis, improve the stability of operation and the durability of the lower structure.
The world-famous brand engine matches the high-power hydraulic transmission system, and the advanced intelligent electronic control system gives full play to the machine's efficiency.
The whole system has high reliability, fuel economy and high reserve power. It can still operate normally in high-cold and high-altitude areas.
Hydraulic system configuration is high, pipeline loss is small, and comprehensive transmission efficiency is high.
| parameter | model | SWDM360H3 | |
| drilling | Maximum drilling diameter | mm | 2500(3000) |
| Maximum drilling depth | m | 102/66 | |
| engine | brand | cummi ns | |
| model | QSX15-C550 | ||
| rated power | kW@rpm | 410@2100 | |
| Power Head | Maximum torque | kN.m | 418 |
| Rotating speed | rpm | 6~25 | |
| Main winch | Maximum lifting force | kN | 390 |
| Maximum lifting speed | m / min | 76 | |
| Wire rope diameter | mm | 40 | |
| Pressurized system | Maximum pressure | kN | 340 |
| Maximum lifting force | kN | 380 | |
| Maximum stroke | mm | 13000 | |
| Vice winch | Maximum lifting force | kN | 110 |
| Maximum lifting speed | m / min | 65 | |
| Wire rope diameter | mm | twenty four | |
| Drill mast | Tilt angle | ° | ±4 |
| Inclination | ° | 5/90 | |
| Chassis | Track width | mm | 900 |
| Crawler telescopic width | mm | 3300~ 4800 | |
| Chassis length | mm | 6120 | |
| Whole machine | Working height | mm | 27200 |
| Working weight | t | 132 | |
We have already exported our products to more than 80 countries and regions, including: Africa, the Middle East, South America, Central Asia, Russia, Mexico, Australia, New Zealand, Holland, British, Mongolia and so on.
we are famous building machinery manufacturer, professional construction machinery exporter and one stop solution supplier in China, our team have more than 15 years experience in this field already.
(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.
(2)Spare parts:CANMAX is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services, wherever you are,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.
(3)Installation & Maintenance:CANMAX is able to provide with the overall installation of complicated machinery,allowing you to start the normal operation of construction machinery solutions.After installation,we will make inspection of the whole machine,operate equipment,and provide you with testing data reports of installation and operation.
(4)Training:CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.
(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity.
Q1:Which country do you export to?
Asia:India,Philippines,Thailand,Burma,Vietnam,Bangladesh,Kazakhstan,Turkmenistan,etc.
Middle east:Saudi Arabia,UAE,Jordan,Oman,Syria,Pakistan,etc.
Europe:Russia,Ukraine,Belarus,Bulgaria,etc.
Africa:South Africa,Kenya,Congo,Ethiopia,Nigeria,Ghana,Algeria,Senegal,Tunisia,etc.
South America:Brazil,Peru,Chile,Cuba,Mexico,etc.
Oceania:Papua New Guinea,Australia,etc.
Q2:What is the proportion of your products export?
75% of our products are exported to all over the world.
Q3:What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers.TT,L/C,D/P,depending on the cooperation time,country and contract value.
Q4:What kind of logistic service do you supply?
FOB,CIF,DAP,ETC.
Q5:What spare parts can you supply?
All kinds of spare parts of xcm g,shantu i,zoomlion,sinotruck,shacman,liugong,san y,sdl g,lonking,xgm a,etc.
