HOWO Dongfeng 4x2 8cbm compressed compactor garbage waste truck
Garbage truck is mainly used in municipal sanitation and large factories and transport all kinds of rubbish, especially suitable for transportation community living garbage.
We provide various types of waste collection vehicles such as side loader, refuse compactor, swing-arm garbage truck, arm-roll garbage truck, sealing dump garbage truck, compression docking refuse collector, kitchen waste truck, etc.
1. Dustbin volume:4~20CBM.
2. Chassis brand: Dongfeng,SINOTRUK,JAC,FAW,FOTON etc.
3. Drive type:4*2, 6*4,8*4
4. Engine:120/
160/180/210/290HP
5. Emission standard:Euro 2/Euro 3/Euro 4/Euro 5.
6. With 3C and passes the ISO9001-2008,SGS.
7.The swing arm garbage truck can be used for multiple dustbins with dump function.
8. OEM, We are a professional manufacturer and can produce all kinds of sizes for swing arm garbage truck.
Technical parameter for garbage truck
| Cabin | Driving type 4x2 | |
| EQ double-door cab, with five seats. 70°hydraulically tillable to the front as attached photo for ref. | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8115x2500x3300 |
| Wheel base (mm) | 4500 | |
| Wheel track (front/rear) (mm) | 1940/1860 | |
| Approach/Departure angle(°) | 25/14 | |
| Weight in KGS | Tare Weight | 7890 |
| Loading Capacity | 6000 | |
| Front axles loading capacity | 1x7000 | |
| Rear axles loading capacity | 1x11000 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Brand | Dongfeng Cummins |
| Model | B190-33 | |
| Horse Power(HP) | 190 HP | |
| Emission standard | Euro 3 | |
| Gearbox | Dongfeng gear box, 6 forwards & 1 reverse | |
| Clutch | Diaphragm spring clutch, diameter 395mm | |
| Steering Gear | Power steering | |
| Fuel tank (L) | 180L | |
| Tire | 10.00-20 All nylon tires with one spare, 7 pieces | |
| Compression box body Size | 8CBM | |
| Tipping hydraulics | Tipping system | Complete set of Chinese brand hydraulics system |
| two advanced two-way-acting hydraulic cylinders | unloading cycling time <60s | Open angle of compressed body: 80° |
| Loading cycling time ≤30s | Lifting capacity ofTurnover mechanism ≥800kg | Rating working pressure of hydraulic system 18Mpa |
