| Transport medium | UN1790 Electronic grade chemical liquid, reagent type chemical liquid | ||
| Volume | 28000L | ||
| Overall Dimension(mm) | 9125*2438*2591 | ||
| Maximum loading capacity (kg) | 30480 | ||
| Working pressure (mpa) | <0.1 | ||
| Design pressure (mpa) | 0.27 | ||
| Pressure at test (mpa) | 0.4 | ||
| Design temperature (ºC) | 50 | ||
| Tank material | S30408 Q345R Q235B | ||
| The shell materat cases | 5~6 | ||
| Eead material thickness | 6~8 | ||
| Internal protective insert | PTFE 3mm | ||
| Baffle-plates | Two double-layered waveguards | ||
| Walkway | Galvanised walkway with movable handrail at Crocodile Point | ||
| Loading type | Top loaded, bottom unloaded. | ||
| Others | Simple Climbing Ladder | ||
| Painting | Acrylic acid and alkali resistant paint, colours can be specified | ||
| Design code | NB/T47064-2017,NB/T47003.1-2009 | ||
| Third Party Inspection | Special Inspection Agency |
Experienced Team choose the most suitable shipping method for different clients among the Containers, Roro and Bulk shipment, balance safety and economic cost.
Cooperate with well known shipping componies, such as MAERSK, NYK, and Wallenius, ensuring the transportation of each shipment.
1. What is your MOQ?
A:One unit.
2. Can you meet my special requirements?
A:Sure! We are a direct manufacturer, we have strong production capacity and research and development capabilities!
3. How is the quality of your products?
A:High quality has always been our advantage. We all use high-quality branded materials with 100% quality assurance. A procedure is established to inspect products, raw materials, process materials, finished materials that have been verified or tested, etc.at all stages of the manufacturing process.
4. How can I get the price of your vehicle?
A:You can contact us through any of the following contact methods. Our personalized service staff will reply you within 24 hours.
5. Is it possible to print our own brand on the vehicle?
A:It's totally acceptable.
6: What is the delivery time?
A:The delivery time is within 30-50 working days after receiving your prepayment.
