Gq70 Light Oil Tank
1 Year
1 Year
Customized
ISO14001, ISO/TS16949, ISO9001
Train Bogies
Railway Freight Wagon
AAR, Uic, Iris
100% QC Passed
Railway: Coals, Ore, Building Mate
Black, Green,White,Yellow,etc.
30-70t
16-24t
OEM\ODM
Kingrail Parts
Wooden Box/Pallet
Wagon
China
8705102300
Product Description
The railway tank wagon is a type of rail freight wagon specialized for the transportation of gas, liquid, and chemical commodities.
Kingrail Parts are capable of manufacturing various types of railway wagons in compliance with AAR, UIC and GOST standards.
Kingrail Parts can produce a variety of tank wagons. include: light oil tank wagons, viscous oil tank wagons, acid tank wagons, cement tank wagons, and compressed gas tank wagons
Specification:
| Main performance parameter | Basic dimension | ||||
| Parameter | Value | Mark | Parameter | Value | Mark |
| loading capacity | 40 t | * | length of wagon | 11000mm | * |
| tare weight | ≤20 t | Bogie base | 7870mm | ||
| axle load | 15 t | * | Max. high of wagon | 385mm | * |
| total volume | 53m3 | * | Max. width of wagon | 2700mm | * |
| valid volume | 52m3 | () Hook center line height(empty car) | 990mm±15mm | * | |
Min. pass radius/curve | 80m | * | |||
operate speed | 100km/h | * | |||
| clearance | From customer | * | |||
| Track gauge | 1000mm | * | |||
| Customer provide or confirm on Customer designate or Eastrail to decide General Determined by Eastrailway | |||||
| Key Part Configuration | Description | Standard | Mark | ||
| Bogie | Ride control | CHINA-TB/T | * | ||
| Draft gear system | 13 | CHINA-TB/T | |||
| Brake system | 120 | CHINA-TB/T | |||
We can customize railway wagons as per clients' specifications and requirements.
1. OEM and customized service.
2. Full machining, primer coating, surface treatment.
3. Complete material testing process.
4. Quality control
If you have any questions, pls feel free to contact us
