Model NO.
highway guardrail
Surface Treatment
Galvanized
Position
Road Side
Material
Iron
Zinc Coating
550g/Sqm
Transport Package
Pallet/Wooden
Specification
WHDC-WB12
Trademark
INNOVAT
Origin
China
Production Capacity
500000 Pieces/Year
After-sales Service:
Installation Instructions
Warranty:
Years
Certification:
ASTM, ISO9001, SGS
Highway guardrail
Guardrail beams we supply are 10 gauge and 12 gauge materials,which process is going through flattening, punching,galvanizing or plastic coating,fabricating and shearing process.We supply and manufacture beam guardrails in accordance with China National Standard JT/T281-1995(Corrugated Sheet Steel Beams For Expressway Guardrail - China), AASHTO M-180(Corrugated Sheet Steel Beams For Highway Guardrail - USA),RAL-RG620 (German) or any other International Standards. The base steel we use meets Steel Grade Q235B (equivalent to S235JR according to DIN EN 10025 andGr. D according to ASTM A283M) or Q345 (S355JR / ASTM A529M 1994).
The company has advanced guardrail plate forming machine, which can realize the strip head removal, smoothing, punching,cutting, forming, leveling and other working procedure, so that the guardrail has good consistency, high processingaccuracy,low production cost, which is widely recognized by the market.
The company has an advanced production line of plastic spraying and hot-dip galvanizing for guardrail .
According to the different construction environment, corresponding surface treatment can be adopted to achieve good corrosion resistance,moisture resistance and weather resistance.
| Name | Specification | material | Surface treatment | Standard |
| W beam | 3520*310* 85*2.5(2.67/2.7/3.0) mm | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| 4130*310*85*2.5(2.67/2.7/3.0 ) mm | ||||
| 4300*306*80*2.5(2.67/2.7/3.0) mm | ||||
| 4300*310*75*2.5(2.67/2.7/3.0) mm | ||||
| 4320*310*85*2.5(2.67/2.7/3.0) mm | ||||
| Thri beam | 4320*506*85*2.55(2.67/2.75/3/4) mm | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| 3300*506*80*2.55(2.67/2.75/3/4) mm | ||||
| 4130*506*83*2.55(2.67/2.75/3/4) mm | ||||
| C post/spacer | 1800*150*75*25*5mm, | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| 1500*100*50*25*5mm, | ||||
| 1500*120*55*16*4/5mm, | ||||
| 1700*150*110*18*4/4.5/5mm | ||||
| 1750*120*55*16*4/5mm, | ||||
| 1900*100*55*25*4/5mm and Customized | ||||
| I post/spacer | H Post Normal size: 1830*157*82*5mm, | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| 1830*157*82*5*7.4mm, | ||||
| 1800*150*100*5mm and Customized | ||||
| U Post/spacer | 1400/1750/1820*150*75*4/4.5/5mm, | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| 1800/1830*176/178*76*4.5/5/6mm, | ||||
| 1830*140*75*5/6mm, | ||||
| 1680/2200*120*80*5/6mm, | ||||
| 2000/1820*150*100*5mm and Customized | ||||
| Round post/spacer | 140x1176x4.5mm OR other length | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| Sigma post/spacer | 100*55*16*4 mm and Customized | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| End section | Fish tail/Single Buffer ends | Q235/345/A26 | Zinc coating ≥550g/m2 or pvc coated | aashto/astm |
| Bolts&nuts&washers | M16*35/40/45/50 | Grade 8.8 | Grade 8.8 | aashto/astm |
| Aluminum Reflectors | 125mm*70mm*75mm(THICK 1.9MM) | / | / | aashto/astm |
Easy installation
Prevent the mobile equipment from skidding off the road by redirecting it
Minimum the damage
High quality material and anti-rust surface for longer service life
Corrosion resistant
Can be repaired quickly after accident
