HTW-RC00X 4 20ma temperature humidity intelligent integrated indoor air quality monitor ir sensor transmitter
The device has a microcomputer linear programming unit and temperature compensating circuit. It uses high precision PT1000 and Humidity-sensitive capacitance as measurement units, designed as protection circuit. It can accomplish measurement of temperature and relative humidity in the myriad wicked environments.
Humi dity transmitter Type | SHT10. SHT11. SHT15 |
Temperature transmitter Type | SHT10. SHT11. SHT15 |
Temperature Sensor Type | PT-1000, PT-100, NTC10K,NTC20K |
Measurement Range of Transmitter | Humidity: 0~100%RH |
Temperature: 0~ 50ºC, 0~ 100ºC, -50~50CºC, -20~-80ºC | |
Power Supply | AC/DC24V±20% |
Output Signal | Curent: 4 20mA Load Resistance < 5002 |
Accuracy | Humidity:±2%,±3%;±5% (30%~ 90%RH) Temperature: ±0.2ºC,±0.3ºC;±0.5ºC |
Wiring Terminals | Plug Port: 3.81mm 4PIN PBT; Screw Steel: M2; Contact Resistance: 20 mΩ |
Wiring Connections | 18~-22 AWG( 1.5 mm²),stripping length: 6~7mm |
Storage Conditions | -20ºC~60ºC(<90%RH),non-condensing |
Surge Immunity | Rate II |
Enclosure material | ABS plastics (Polycarbonate ),White |
Weight | 82 ±5g Pro-environment: ROHS |
Pro-environment | RoHS |
Illustrate:
1. The terminals of Pow and Com are the power supply When using 24Vdc input, please note that the Pow connects to anode("+"),the Com connects to the cathode ("-")(The device is reverse voltage protected and will not work if connected backwards): when using 24V AC input, don't need to consider the anode and cathode too much, but the consideration of the code for electrical deign and installation, advice that the Pow connect the HOT and the Com connect to the NEUTRAL.
2."Rt"is the terminal of the temperature resistance signal out, when measuring the temperature, the sensor option output is on the two terminals marked "Rt"and "T".
HTW-RC00X 4 20ma temperature humidity intelligent integrated indoor air quality monitor ir sensor transmitter is the special device of temperature measurement that applys the HVAC duct systems, modern buildings, smart air conditioners, cabinets, base stations, subways, airports and other places.
Q: Are you a factory/manufacturer?
A: Yes, we are professional factory/manufacturer of weather station and relative weather sensors. We also have hot sale and widely used duct temperature and humidity transmitter HTW-IE00X.
Q: What's the power supply and signal output?
A: Common power supply and signal output is DC24V, 4-20mA.
Q: Does this product work in wet conditions?
A:This sensor is waterproof,but in order to prevent the water, please don't damage the waterproof of the shell when mounting the device, mount the OSA enclosure with the sensor module facing down.
Q: How can I collect data?
A: If you have your own data logger, you only need to buy our sensor and meanwhile we send you communication protocol.
If you do not have, we can add our data logger for you, also provided with English software, which can help you read, inquire and download data.
Q: What's the lifetime of this temperature humidity module?
A: At least 5 years long. Every sensor has its own calibration certificate or testing report.
Q:What's the delivery time?
A: Usually, we dispatch goods in 3-5 working days after receiving your payment. But it depends on your quantity.
Q: May I know your warranty?
A: Yes, usually it's 1 year. We can send you detailed warranty document if needed.
Q: What's enclosure material?
A: It's ABS plastics (polycarbonate ), white.
