Veinasa-LXP-21
Tunnel Illumination Detector
RS485, 4-20mA
Plastic
Waterproof
Customized
0-20000lux
Vertical ≥20º Horizontal ≥20º
1% - 5%
-40ºC -- -65 ºC
0-100%Rh (Non-Condensing)
LCD Real-Time Display
220VAC 50Hz
≤2W
IP66
Wall Mounting
3kg
Veinasa
Covered with Carton Package
3KG
China
Product Description
Veinasa-LXP-21 Tunnel Illumination Detector Tunnel Brightness Sensor Entrance Light Motion Light Intensity Sensor
Veinasa-LXP-21Tunnel Illumination Detector is a fully intelligent detector designed with the most advanced VLSI technology and proprietary digital analog hybrid communication technology.
The product has advanced technology, high stability, communication and alarm functions, easy installation and maintenance. It is widely used in the illumination detection of tunnel entrance.
| Test range | 0-20000LUX |
| Measuring Angle | Vertical ≥20º Horizontal ≥20º |
| Test accuracy | 1% - 5%. |
| Ambient temperature | -40ºC -- -65 ºC |
| Ambient humidity | 0-100%RH (non-condensing) |
| Numerical display | LCD real-time display |
| Communication interface | One way 4-20mA, maximum impedance 500 ohms One digital RS485 output One relay output, fault alarm |
| Supply voltage | 220VAC 50HZ |
| Power dissipation | ≤2W |
| Class of protection | IP66 |
| Installation mode | Wall mounting |
| Machine weight | 3KG |
Dimensions:
Installation:The sensor is an integrated sensor without any moving parts.
The installation position should be on the right side wall in the direction of the vehicle and on the side wall twice the net height of the tunnel entrance. The recommended installation height is 3 meters.
1. The digital and intelligent detection of tunnel brightness is fully realized;
2.4-20mA current signal and standard RS485 digital interface, can achieve communication with the computer;
3. Digital tube display detection value, viewing intuitive and convenient;
4. Site maintenance is safe, convenient and fast;
2.4-20mA current signal and standard RS485 digital interface, can achieve communication with the computer;
3. Digital tube display detection value, viewing intuitive and convenient;
4. Site maintenance is safe, convenient and fast;
This Tunnel Illumination Detector is widely used in brightness detection of tunnel entrance to realize automatic lighting control.
Q: Are you a factory/manufacturer?
A: Yes, we are professional factory/manufacturer of weather station and relative weather sensors. We also have hot sale and widely used visibility meter DSC3013.
Q: What's the main characteristics of this sensor?
A: Congratulations, it's easy for installation and maintenance, factory price but amazing quality.
Q: What's the common power supply and signal output?
A: Common power supply and signal output is 220VAC, RS485 and 4-20mA. But we can customize for you as demands.
Q: What's the lifetime of this sensor?
A: At least 5 years long. Every sensor has its own calibration certificate or testing report.
Q: May I know your warranty?
A: Yes, usually it's 1 year. We can send you detailed warranty document if needed.
With rich experiences in tackling problems, Veinasa aims to provide a package of meteorological solutions to your needs, whatever problems you encounters, Veinasa team always stand by your side.
Just click the below picture to send us inquiry, to know more, or get the latest catalogue and competitive quotation. Do not hesitate!
