SM41PB
Cantilever Type
Resistance Strain
4-Wire
Digital Type
SemiConductor
Normal Wirewound
Stainless Steel
IP67
ISO
Customized
2.5t - 20t
GB/T 7551-2008 Certificate
10~12 VDC
≥5000 MΩ(Mege-Ohms)
-40~+85ºC
Sun-Moon
Stendard Package
Export
China
9031809090
Product Description
Description:
SM41PB bearing type sensor adopts bridge structure, low installation height, large contact area, good rigidity, long service life, suitable for all kinds of harsh environment. Used for all kinds of lifting equipment, load limit protection device installation.
characteristic :
Costing high sensitivity and reliability; High stability.
Adopts a movable head structure, which ensures good lateral force and impact resistance.
Features a protective seal for dust and moisture protection and works well in harsh environmental conditions.
X-ray measurement body material adopts high-performance alloy steel or stainless steel;
The safety overload range of the ontology is 150% F·S.
Participates in the industrial design, protection grade IP67;
Giga operates at a temperature range from -40 ° C to +85 ° C
Dimensions (In mm. 1mm=0.03937 inches)
| CAP./SIZE(range/SIZE) | A | B | C | D | E | H | L | K | h1 | h2 | 4-Φ1 | 6-Φ2 | 6-Φ3 |
| 2.5t | 350 | 200 | 75 | 140 | 40 | 36 | 100 | 50 | 16 | 3 | 17 | 22 | 14 |
| 4 | 420 | 350 | 100 | 160 | 60 | 37 | 120 | 70 | 21 | 2 | 22 | 26 | 18 |
| 6 | 420 | 350 | 100 | 160 | 60 | 41 | 120 | 70 | 21 | 1 | 22 | 26 | 18 |
| 8 | |||||||||||||
| 10 | |||||||||||||
| 12 | 450 | 380 | 120 | 200 | 80 | 45 | 140 | 70 | 26 | 1 | 24 | 33 | 22 |
| 15 | |||||||||||||
| 20 | 460 | 420 | 160 | 230 | 80 | 45 | 160 | 80 | 26 | 1 | 24 | 33 | 22 |
Circuit Diagram :
Specification| Type | Technical parameters |
Nominal load range | 2.5~20t |
| Power supply | 10~12 VDC |
Sensitivity | 2.0±0.005mV/V |
Temperature Effect On Zero | ±0.02%FS/10ºC |
Temperature Effect On Output | ±0.02%FS/10ºC |
Input resistance(Rlc) | 760±20Ω(ohms) |
Output resistance(Ro) | 700±5Ω(ohms) |
Insulation resistance | ≥5000 MΩ(Mege-Ohms) |
| Class precision | 0.03%FS |
| ≥5000 MΩ(Mege-Ohms) | -40~+85ºC |
| Safe Load Limit | 150% FS |
| Safety margin against breakage | 200% FS |
Material material | (15%) High performance alloy steel or (chromium ratio>15% stainless steel) |
| Protection type | IP67 |
Company Profile
The SUNMOON was founded in 1988. In 1995, the first batch of High-tech enterprises were recognized as national state-level. The SUNMOON also passed the certification of ISO 9001 Quality Management System,ISO14001 Environmental Management System and OHSAS 18001 Occupational Health and Safety Assessment Series. With SM series of products measuring instruments manufacturing license qualification and a variety of explosion- proof measurement and control products production qualification,mechanical and electrical equipment installation engineering professional contracting qualification. With independent intellectual property rights of the patented technology189terms. These is the SUNMOON's core competitiveness of the technology.
The subject positioning classification of the SUNMOON's products is "Sensing and loT Technology"-sensor manufacturing and sensor application technology, information acquisition and processing technologies,loT technology and applications.These is the pioneer of modern high technology.
The SUNMOON products are positioned to "reliably and steadily meet the harsh environment of the industrial site". The whole products system with forward-looking technology, application is convenient, the configuration is universal, now has more than 9000 number of clients from all walks of life. Have SM series weighing, load, pressure, torque, displacement, velocity, temperature and humidity sensors and the corresponding transmitter or amplifier, an annual output of 300 thousand units; an annual output of 20 thousand sets of all kinds of instrument; all kinds of projects completed 2000 terms of the annual capacity.
The SUNMOON take Nanjing City as a scientific research base, making full use of Nanjing's talent advantage and international interests.With Bengbu City covers an area of 50,000 m'as the production and after-sales service base, and with local service as the goal, all the branches in different parts of the Country have jointly formed a complete scientific research, production and after-sales service system platform, which guarantees that The SUNMOON are in the lead of science and technology, innovation and forever the first. These is the SUNMOON's core competitiveness of the mechanism!
