Qae2121.010 Qae2120.010 Qae2111.010.   Immersion Temperature Sensor, Passive

QAE21..  Immersion temperature sensor, passiveStock no. BPZ:QAE21..



Additional info
Fixing is made by protection pocket or compression fitting. If for the nominal pressure no entry can be found in the table, no protection pocket is included as standard and the nominal pressure depends on the protection pocket used (see accessories). By using the compression fitting AQE2102 the nominal pressure is 16 bar (PN16).

QAE21..  Immersion temperature sensor, passive Stock no. BPZ:QAE21.. Additional info Fixing is made by protection pocket or compression fitting. If for the nominal pressure no entry can be found in the table, no protection pocket is included as standard and the nominal pressure depends on the protection pocket used (see accessories). By using the compression fitting AQE2102 the nominal pressure is 16 bar (PN16). Attribute Value Time constant With protection pocket: 30, Without protection pocket: 8 s Material, immersion pocket Stainless steel Connection, electrical Screw terminals Degree of protection IP42 Dimensions (W x H x D) 80 x 60 x 31 mm Product Variants  QAE2111.010 - Immersion temperature sensor 100 mm Pt100, without protection pocket  QAE2111.015 - Immersion temperature sensor 150 mm Pt100 without protection pocket  QAE2112.010 - Immersion temperature sensor 100 mm Pt1000 without protection pocket  QAE2112.015 - Immersion temperature sensor 150 mm Pt1000 without protection pocket  QAE2120.010 - Immersion temperature sensor 100 mm LG-Ni1000, with protection pocket  QAE2120.015 - Immersion temperature sensor 150 mm, LG-Ni1000, with protection pocket  QAE2121.010 - Immersion temperature sensor 100 mm, LG-Ni1000, without protection pocket  QAE2121.015 - Immersion temperature sensor 150 mm LG-Ni1000, without protection pocket  QAE2130.010 - Immersion temperature sensor 100 mm NTC 10k without protection pocket  QAE2130.015 - Immersion temperature sensor 150 mm NTC 10k without protection pocket

Product Variants
 QAE2111.010 - Immersion temperature sensor 100 mm Pt100, without protection pocket
 QAE2111.015 - Immersion temperature sensor 150 mm Pt100 without protection pocket
 QAE2112.010 - Immersion temperature sensor 100 mm Pt1000 without protection pocket
 QAE2112.015 - Immersion temperature sensor 150 mm Pt1000 without protection pocket
 QAE2120.010 - Immersion temperature sensor 100 mm LG-Ni1000, with protection pocket
 QAE2120.015 - Immersion temperature sensor 150 mm, LG-Ni1000, with protection pocket
 QAE2121.010 - Immersion temperature sensor 100 mm, LG-Ni1000, without protection pocket
 QAE2121.015 - Immersion temperature sensor 150 mm LG-Ni1000, without protection pocket
 QAE2130.010 - Immersion temperature sensor 100 mm NTC 10k without protection pocket
 QAE2130.015 - Immersion temperature sensor 150 mm NTC 10k without protection pocket
