Hand Stacker with Double Action Hydraulic (HL-KS Series)

Hand Stacker with Double Action Hydraulic (HL-KS Series)


1.Lifted by towbar and lowered by manual controal
2.Double action hand pump provides quicker lifting
3.Mechanical switch for unloaded and loaded lift
4.Chain drive steering system offer a maximum manoeuvrability with 180 degree turning angle
Conforms to EN1757-1



Model			HL-KS1015		HL-KS1023		HL-KS1027
Capacity		KG	1000		1000		1000
Max.Fork Height		MM	1500		2300		2750
Min.Fork Height		MM	90		90		90
Lifting per Stroke		MM	30		30		30
Fork Length		MM	1170		1170		1170
Fork Width		MM	160		160		160
Overall Fork Width		MM	540		540		540
Front Load Roller		MM	78x80 nylon		78x80 nylon		78x80 nylon
Steering Wheel		MM	150x55 nylon		150x55 nylon		150x55 nylon
Overall Length		MM	1720		1720		1720
Overall Width		MM	700		700		700
Overall Height		MM	1950		1700		1700
Qty in 1x20 CTN		pcs	23		23		23
Net Weight		KG	240		260		270
