SWDA200C
Video Technical Support, Online Support, Spare PAR
1 Year
New
DC Motor
150-200mm
<100m
Diamond Bit
Impactor
Efficient and Intelligent
180-255
146
2.07
10m*3
82/2200+74
30t
Elevated Down-The-Hole Drilling Rig
D Miningwell
Sea Freight; Land Freight
8400*4680*13800 mm
Zhejiang, China
Product Description
| Technical parameters of Overhead diesel-electric integrated DTH drill rig | |||
| Model | SWDA165C | SWDA200C | SWDA250C |
| OPERATION PARAMETER | |||
| Hole diameter(mm) | 138-180 | 180-255 | 230-270 |
| Hole depth(m) | 25 | 30 | 30 |
| Rod diameter(mm) | 114 | 146 | 146 |
| Rod length(m) | 8.5m*3 | 10m*3 | 10m*3 |
| Hammer size | 5", 6" | 6", 8" | 8", 9" |
| Dust collector | Dry type(Standard) / Wet type(Optional) | ||
| AIR COMPRESSOR | |||
| Working pressure(Bar) | 1.38 | 2.07 | 20.7 |
| Air displacement(m3/min) | 21.2 | 28.3 | 32.6 |
| Power(kW/rpm) | 185 | 250 | 280 |
| ENGINE(Diesel engine and electric motor integrated) | |||
| Model | Cummins QSB4.5+Y2-200S-4 | Cummins QSB4.5+Y2-225S-4 | Cummins QSB4.5+Y2-225S-4 |
| Power(kW/rpm) | 82/2200+60 | 82/2200+74 | 97/2200+74 |
| Fuel tank capacity(L) | 200 | 200 | 200 |
| FEED | |||
| Feed beam length(mm) | 11500 | 13200 | 13200 |
| Feed Stroke(mm) | 9000 | 10500 | 10500 |
| Feed extension(mm) | 1800 | 1800 | 1800 |
| Feed rate.Max(m/s) | 0.8 | 0.8 | 0.8 |
| Feed force.Max(kN) | 60 | 75 | 75 |
| Forward tilting angle(°) | 90 | 90 | 90 |
| TRAVEL CAPACITY | |||
| Travel speed(km/h) | 2.8 | 2.8 | 2.8 |
| Traction force,MaxkN) | 125 | 175 | 175 |
| Gradeability(°) | 25 | 25 | 25 |
| Ground clearance(mm) | 480 | 480 | 480 |
| ROTARY | |||
| Rotary speed(rpm) | 85 | 50 | 50 |
| Rotary torque(Nm) | 5500 | 6000 | 6620 |
| DIAMENSION | |||
| Gross weight(T) | 28 | 30 | 32 |
| L*W*H Working(mm) | 8400*4650*12000 | 8500*4680*13800 | 7500*4680*13900 |
| L*W*H Transportation(mm) | 12000*3400*3500 | 13800*3400*3500 | 13900*3350*3450 |
