Product Description
Our truck-mounted water well drilling rig is a customized product that customers can customize according to their actual needs. Customers can choose from: chassis brand, boom length, mud pump selection, chassis installation air compressor and so on. The vehicle-mounted water well drilling rig is divided into different models according to the drilling depth, the maximum depth can reach 1500 meters.
| Specifictaion table of MWT400 Truck mounted water well drill rig | |
| Model | MWT400 |
| OPERATION PARAMETER | |
| Hole diameter | 140-400mm |
| Hole depth | 400m |
| Rod diameter | 102/114mm |
| Tower lenth | 6.6m |
| Engin | Full Power PTO |
| Lifting Power | 25 Ton |
| Lifting Speed | 25/40 m/min |
| Hoist Lifting Power | 2 Ton |
| Torque Power | 7000-9500N.m |
| Torque Speed | 50-135rpm |
| Penetration Speed | 15-35m/h |
| AIR COMPRESSOR(Optional) | |
| Working pressure | 25bar |
| Air displacement | 31 m3/min |
| Engine | FAW 310kw |
| Truck | |
| Brand | Sino HOWO |
| Model | 6*4 |
| Engine | Wechai 290hp(336hp/371hp) |
| Other Optional parts | |
| Foam pump | 35L/min; 21Mpa |
| Mud pump | 850L/min; 2Mpa |
| Rod unloader | |
| Welding machine | |
Customers Feedback
Shipping Pictures
D Miningwell Team
D Miningwell equips all rock drilling equipment with high-quality friction welded drill rods. The threads, rod bodies and welded joints of the drill pipes have been rigorously processed.
Sufficient Stock-Fast Delivery
