Model NO.:

YEJ2

Application:

Universal

Operating Speed:

1000rpm/1500rpm/3000rpm

Number of Stator:

Three-Phase

Species:

Y, Y2 Series Three-Phase

Rotor Structure:

Winding Type

Casing Protection:

Closed Type

Number of Poles:

2/4/6/8

Starting Mode:

Direct on-line Starting

Certification:

ISO9001, CCC

Brand:

Maxmach

Color:

Blue

Duty Type:

Continuous(S1)

Rated Frequency:

50Hz/60Hz

Rated Voltage:

380V

Power Range:

0.12-45kw

Seat Center Height:

63-160mm

Insulation Class:

B/F

Protection Level:

IP54/IP55

Working System:

Trademark:

Maxmach

Transport Package:

Packing in Wooden Cases and Carton Cases

Specification:

630*310*410

Origin:

Ningbo

HS Code:

84743100

Product Description

Electromagnetic Brake Three-Phase Asynchronous Motor YEJ2 Series Automatic Brake Motor

YEJ2series electromagnetic brake three-phase asynchronous motors are improved products of YEJ series,it is in accordancewith JB/T6456-2010 requirements,and its electrical performance is in accord with YE2 series technical standard.The electricpower of the controller should be synchronized with the electric power of the motor.
The electric motors are equipped the electromagnetic brake on the non-shaft end,when electricity off,retarding disc willautomatically pr-ess in end-shield which produce friction brake torque and stop the running of motor,the no-load brakeduration is changed with the frame size of the motor,the range is 0.15-0.45 seconds.This kind of motor is considered as thedriving force of various machinery and widely used in mechanical workout machine tool,transport machinery,package,woodworking,food,chemical engineering,textile,construction,shop,roll door machinery.

Technical Data
Type YEJ2	kW	r/min	A	Eff n%	P.F	Nm	S		Tst Tn	Tmax Tn	lst In	kg
Synchronous speed 3000r/min
YEJ2-631-2	0.18	2720	0.53	65	0.80	4	0.20	18	5.5	2.2	2.2	12
YEJ2-632-2	0.25	2720	0.69	68	0.81	4	0.20	18	5.5	2.2	2.2	13
YEJ2-711-2	0.37	2740	0.99	70	0.81	4	0.20	18	6.1	2.2	2.2	14
YEJ2-712-2	0.55	2740	1.40	73	0.82	4	0.20	18	6.1	2.2	2.3	15
YEJ2-801-2	0.75	2845	1.83	75	0.83	7.5	0.20	30	6.1	2.2	2.3	17
YEJ2-802-2	1.1	2840	2.58	77	0.84	7.5	0.20	30	7.0	2.2	2.3	18
YEJ2-90S-2	1.5	2840	3.43	79	0.84	15	0.20	50	7.0	2.2	2.3	23
YEJ2-90L-2	2.2	2840	4.85	81	0.85	15	0.20	50	7.0	2.2	2.3	26
YEJ2-100L-2	3.0	2860	6.31	83	0.87	30	0.20	65	7.5	2.2	2.3	37
YEJ2-112M-2	4.0	2880	8.10	85	0.88	40	0.25	90	7.5	2.2	2.3	45
YEJ2-132S1-2	5.5	2900	11.0	86	0.88	75	0.25	90	7.5	2.2	2.3	59
YEJ2-132S2-2	7.5	2900	14.9	87	0.88	75	0.25	90	7.5	2.2	2.3	72
YEJ2-160M1-2	11	2030	21.3	88	0.89	150	0.35	150	7.5	2.2	2.3	120
YEJ2-160M2-2	15	2930	28.8	89	0.89	150	0.35	150	7.5	2.2	2.3	150
YEJ2-160L-2	18.5	2930	34.7	90	0.90	150	0.35	150	7.5	2.2	2.3	149

Price	$200.00 / Piece
Mini Order	-+Subtotal: $2000
Availability	In Stock
