wecher
1 Year
1 Year
Electric
11, 11
Factory, Station, Wharf, Port, Airport, Mall, Hospital, School, Villa, Resort, Pedestrian Street, Hotel, Golf Course, Amusement Park, Scenic Spot
Black, Yellow, Blue, White
Standard
Electric Bus
OEM
Wooden Case
large
China
Product Description
 |  | ||
Main technical parameters | Vehicle basic configuration table | ||
| brand: | FUQ | 1. Body: the body is one stamping body + ABS engineering plastic interior 2. Chassis: enhance the chassis of the micro car and optimize the anti-rust paint treatment 3. Front windshield: special tempered glass for automobiles, equipped with windshield wiper. 4. Seat: front seat (1 + 1 leather fabric high rebound PU + armrest, corner regulator) rear seat (double row seat 1 + 1 leather fabric high rebound PU + armrest) 5. Floor leather: non-skid floor leather. 6. Instrument panel: digital instrument panel, combined switch, power indicator, steering indicator. 7. Sound system: radio, SD card, MP3 player with audio. 8. Direction system: the left and right double push gear rack steering system. 9. Light / horn: front lights, turn signal, rear taillights, horn, reversing buzzer. 10. Motor: AC motor, power: 72V 4KW. 11. Battery: 12V6 * 100 AH / 72V maintenance-free battery. 12. Electronic control and acceleration system: Inbol electronic control system. 13., Charger: High-frequency pulse computer control intelligent charger, automatically stop after charging, can effectively prolong the battery life. 14. Front axle and suspension: McPherson type independent suspension. 15. Rear bridge and suspension: integral rear bridge + non-independent suspension. 16. Brake system: equipped with vacuum brake power, front and rear hub brake four-wheel hydraulic brake, brake system and mechanical parking (hand brake), stronger safety and higher stability. 17. Tire: aluminum alloy mirror polished wheel hub + luxury vacuum tire. | |
| model: | wecker | ||
| Number of passengers: | 11 persons (including drivers) | ||
| Size: length, width and height | 5100*1510*1920mm | ||
| complete vehicle kerb mass: | 980kg | ||
| Rated load: | 1150kg | ||
| wheel base: | 3450mm | ||
| front gauge: | 1290mm | ||
| rear track: | 1280mm | ||
| Minimum ground clearance: | 290mm | ||
| Max. vehicle speed (full load): | 30km/h | ||
| braking length: | ≤6m | ||
| minimum turning radius: | ≤7m | ||
| Maximum ramp level (full load): | 25% | ||
| Parking capacity (no-load): | 15% | ||
| Motor rated power: | 72v 4KW | ||
| controller | Inber Smart Controller | ||
| cell | 12V*100AH | ||
| charging interval: | 8-10 Hours | ||
| driving range: | ≥80km | ||
| tyre: | 165R13 | ||
| Model advantage | 1, advantages: the body as an integrated stamping body + ABS engineering plastic interior design, long service life, corrosion resistance, lightweight design. 2, Configuration: battery lead acid large capacity deep cycle battery 12v100ah / 6 pieces, power 72V 4KW motor. 3, free: the body color can be painted according to customer requirements, free design logo | ||
| Warranty period | Free door-to-door service starts from the date of product acceptance, and the warranty period is one year | ||
