EBZ132
Overseas Service Center Available
1year
CE, ISO 9001:2008
New
AC Motor
>300mm
>300m
Multifunction
Mobile Gyrator
0~6m/Min
5700kg
XCMG Official Ebz132 Boom-Type Roadheader Tunnelin
38.3ton
220mm
220mm
405mm
132kw
75kw
4.16m
XCMG
Comply with Export Packaging Requirements
3.24x1.39x1.29m
Jiangsu China
84301000
Product Description
XCMG Official Ebz132 Boom-Type Roadheader Tunneling Machine .
Roadheader series product is modern mechanical equipment for roadway excavation, covering over 10 specifications, types of light weight, medium weight and heavy weight with cutting power of 50KW to 315KW, cutting hardness of f4 to f12, which is applicable for the rapid excavation of coal, semi-coal and whole-rock roadway with cutting cross section of 3.8 to 42m2 and also applicable to the excavation of other mines, highway, railway and roadway of water conservancy project under similar condition.
EBZ132 boom-type roadheader is a kind of integrated and efficient heading equipment which integrates cutting, shipping and walking, and is applicable to thin-seam coal roadway or semi coal-rock roadway.
1, Low body, underslung, with high stability and great grade ability;
2, Adopt fixed head, with good rigidity and high strength; suitable for semi coal-rock roadway;
3, High cutting power and traction, strong adaptability and high heading efficiency;
4, Adopt small-diameter cutting head, with strong single-pole force, reasonable cutting pick arrangement, strong cutting capacity, low cutting vibration and high working stability;
5, Equipped with the function of internal and external spraying, with the external spraying reasonably optimized for dust suppression;
Mounted with arc-shaped star wheel to minimize coal reclaiming and improve the loading efficiency;
6, The walking reducer adopts imported highly-integrated structure, with small size and high reliability.
| Total length (m): | 8.92 | Rotate speed of the star wheel (r/min): | 36 |
| Total width (m): | 2.60 | Scraper chain speed (m/min): | 61 |
| Total height (m): | 1.40 | Traveling speed (m/min): | 0~6 |
| Total weight (t): | 38.6 | Dimension of the largest non -detachable part (m): | 3.24×1.39×1.29 |
| Cutting depth (mm): | 270 | Weight of the largest non-detachable part (kg): | 5159 |
| Ground clearance (mm): | 220 | Power supply voltage (V): | AC1140/660 |
| Gantry height (mm): | 400 | Electric cutting motor (kW): | 132 |
| Grade ability: | ±18° | Oil pump motor (kW): | 75 |
| Pressure to the ground (Mp): | 0.14 | System pressure (Mpa): | 18 |
| Maximum heading height (m): | 3.5 | Variable piston double pump (ml/r): | 145+145 |
| Maximum positioning heading width (m): | 4.7 | Travel motor (ml/r) | 125 |
| Rotate speed of the cutting head (r/min) | 44 | Shovel plate motor (ml/r): | 1340 |
| Head expansion range (m): | Fixed | The first conveyor motor (ml/r): | 400 |
| Economic cutting hardness (Mp): | ≤75 | Traction (kN): | ≥200 |
