CIMC9230
Semi-Trailer
30T
ISO9001, CCC, ISO/TS16949
7000-8000mm
1820mm
Heavy Duty
Cross Arm Type
Open Shape
3
12
Not Self-dumping
ABS Anti-lock Braking System
Iron
New
Fuwa Axle, 13 Ton Capacity/Set, 3PCS
Leaf Spring Suspension
2"(50#) or 3.5"(90#)
Jost E100
10r20
for Car / Vehicle Transportation
as Customers' Request
for 5-8 Cars
Yes
Cimc
3mm Thickness
CIMC
Nude Packing
ISO, TS16949, CCC
Jiangsu, China
871639900
Product Description
Cimc Double Level Opened Design Car Carrier Truck Trailer Car Trailer
SPECIFICATION
Type:CAR CARRIER
DIMENSION:
Overall Length: 17,100 mm
Overall Width: 2,780 mm
Overall Height: 4,250 mm
King Pin Setting: 1,200 mm
Wheel Span: 9,470 mm
Axle Spacing: 1,350mm+1350 mm
RUNNING GEAR:
Suspension: Underslung tandem-axle suspension with equalizer; 6-leaf spring.
Axle: Three TSU axles with 10,000 kg capacity per axle.
Brake: Dual lines pneumatic brake system.
Parking Brake: Type 30 spring brake system on front axle and type 30/30 on rear two axle.
Wheel:7.5-22.5 ,7pcs (including One spare wheel)- made in China.
Tire: 11R22.5-16PR, 7pcs (including One spare tire) - made in China
King Pin : JOST 2"
LANDING LEG:TSU two speed manual operation type with sand shoes.
ELECTRICAL:
Voltage: 24 Volt.
Receptacle: 7 way
Light: Front marker lamp: white ; Side marker lamp: amber
Rear lamp: red; Direction-indicator lamp: amber
STRUCTURAL WEIGHT RATTING:
Tare Weight: 11,500 Kg.
Payload: 14,000 Kg.
G.V.W.R.: 25,500 Kg.
King Pin Weight: 8,300 Kg.
Axle Weight: 17,200 Kg.
CONSTRUCTION:
Structure: Two "I" beam made of low-alloy steel, with cross members. All welded steel structure.
Hydraulic system: Up platform can be adjusted up and down by hydro-cylinder, totally 10 pcs of cylinder in each trailer. Hydraulic System is driven by Electrical Motors.
Painting: Painting color according to customer's requirement.
Accessories: wheel stoppers with wheel tightening straps - 32 sets.
Contact
Mr. Allen
Mobile : +86 151 5082 2016
Company information
CIMC VEHICLES SALES CO., LTD.
CIMC VECHICLE was founded by CIMC group, which fixes the mission to be customers' partner for modern transportation. CIMC is dedicated to manufacturing and supplying CIMC trucks, CIMC truck body assembly, trailers, tank equipment. Currently, CIMC owns USD 8.8 billion total assets, USD 2.6 billion net assets, USD 8.4 billion annual sales and USD 0.6 billion net profits in 2010, having over 150 subsidiaries and 63, 000 staff across China, North America, Europe, Asia and Australia.
Vehicles: CIMC has over 1000 lines of products in 11 series, including container chassis, flatbed trailer, bulk lorry, tanker, self-dumper, reefer trailer, van, curtain side trailer, mixer, pump truck, car carrier vehicle, fire engine, sanitation vehicle, etc. With the annual output capacity of over 200 thousand units, it now takes the leading position in the world. Up to today, the Group has established 22 production bases.
Heavy Truck: Have its own production C & C brand truck. Other heavy truck CIMC produces the truck body, more than 2, 000 kinds of truck body for different transportation purpose. The truck chassis cooperates with FAW, DONGFENG DFAC, SHACMAN, SINOTRUK, FOTON, BEI BEN, JAC, CAMC, SI CHUAN HYUNDAI, SAIC-Iveco and so on, include all truck chassis brand production in China.
Welcome global heavy truck dealer to take a sight seeing of trucks, to taste values of "considerate service, benefits share"! Will bring you cost-saving solutions and eye-catching returns!
Address: 8floor, Cimc Plaza, No. 10 West Wenchang Rd, Yangzhou, Jiangsu, China
Tel:86 - 514 - 8282 6119
Fax:86 -514-8732 5750
Website:yzcimc.en.made-in-china.com
Mobile:86-151-5082-2016 (Mr.Allen)
SPECIFICATION
Type:CAR CARRIER
DIMENSION:
Overall Length: 17,100 mm
Overall Width: 2,780 mm
Overall Height: 4,250 mm
King Pin Setting: 1,200 mm
Wheel Span: 9,470 mm
Axle Spacing: 1,350mm+1350 mm
RUNNING GEAR:
Suspension: Underslung tandem-axle suspension with equalizer; 6-leaf spring.
Axle: Three TSU axles with 10,000 kg capacity per axle.
Brake: Dual lines pneumatic brake system.
Parking Brake: Type 30 spring brake system on front axle and type 30/30 on rear two axle.
Wheel:7.5-22.5 ,7pcs (including One spare wheel)- made in China.
Tire: 11R22.5-16PR, 7pcs (including One spare tire) - made in China
King Pin : JOST 2"
LANDING LEG:TSU two speed manual operation type with sand shoes.
ELECTRICAL:
Voltage: 24 Volt.
Receptacle: 7 way
Light: Front marker lamp: white ; Side marker lamp: amber
Rear lamp: red; Direction-indicator lamp: amber
STRUCTURAL WEIGHT RATTING:
Tare Weight: 11,500 Kg.
Payload: 14,000 Kg.
G.V.W.R.: 25,500 Kg.
King Pin Weight: 8,300 Kg.
Axle Weight: 17,200 Kg.
CONSTRUCTION:
Structure: Two "I" beam made of low-alloy steel, with cross members. All welded steel structure.
Hydraulic system: Up platform can be adjusted up and down by hydro-cylinder, totally 10 pcs of cylinder in each trailer. Hydraulic System is driven by Electrical Motors.
Painting: Painting color according to customer's requirement.
Accessories: wheel stoppers with wheel tightening straps - 32 sets.
Contact
Mr. Allen
Mobile : +86 151 5082 2016
| Trailer Model | CIMC car transport semi trailer,car carrier truck trailer |
| Overall Dimension(Lx W x H)(mm) | 15000*2500*3990 |
| Function | For car/vehicle transportation |
| Pay Load | For 5-8 cars |
| Main Frame | 350mm height I beam, Top Flange 10mm, Middle Flange 6mm; Bottom Flange 12mm |
| Floor | 3mm thickness |
| Axle | 2 special vehicle axles, FUWA brand |
| Suspension | Leaf Spring suspension |
| Landing gear | 28T, manual operating, heavy duty |
| Tyre | 10R22.5 (8 pcs) |
| Spare Wheel Carrier | One set of spare wheel & Tyre carrier including a riser. |
| Braking system | Dual line-air brake, piggyback spring on all axles; four units of T30/30 spring brake chamber. four lifting hydro-cylinder. Three aircraft jump frames. |
| Electric System | One unit of JAEGER POWAY, 24V 7-pin ISO1185 standard socket; Standard Tail lamp with turn signal, brake light & reflector, Side lamp etc. One set of 6-core standard Cable |
| Painting | Sand blasting processing on rust-proof protection. One coat of anticorrosive primer, two coats of finish urethane paint, Color as customer choice. |
| others | Hydraulic dump and other fittings |
