BZC400BCA
New
AC Motor
>300mm
>200m
Cone Bit
Rotary
Water Well Drilling Machine
Petroleum Drilling and Production Equipment
Water Well
Diesel
400
500
250
250
12503
11510*2480*2800
19340
KUDAT
Naked Packing
China
8430412900
Product Description
| Technical parameter | |||
| Drilling depth(M) | 400 | ||
| Drilling diameter(mm) | 500 | ||
| Speed of turntable(r/min) | 117; 102; 60; 38; 22; 13; 14(reverse) | ||
| Torque of turntable(KN.m) | 7.5------75 | ||
| Single rope lifting capacity of main windlass(KN) | 40 | ||
| Maximum lifting capacity of main windlass(KN) | 240 | ||
| Single rope lifting capacity of assistant windlass(KN) | 40 | ||
| Single rope lifting capacity of assitant windlass(KN) | 160 | ||
| The lifting capacity of hook(KN) | 250 | ||
| Bearing capacity of drilling tower (KN) | 250 | ||
| The height of drilling tower (mm) | 12503 | ||
| Drill pipe | Kelly bar(mm) | 108×108×7500 | |
| Assistant pipe (mm) | 89×10×5700 | ||
| BW850/2A plunger pump | Diameter of cylinder (mm) | 150 | |
| Stroke of piston (mm) | 180 | ||
| Theoreical flow (L / min) | 600 850 | ||
| Rated pressure (Mpa) | 3 2 | ||
| Pounding times (min -1 ) | 58 82 | ||
| Diameter of suction tube (mm) | 127 | ||
| Diameter of drain pipe (mm) | 64 | ||
| Input speed (r / min) | 470 | ||
| Input power (kw) | 40 | ||
| Overall dimensions (mm) | 2000*1030*1400 | ||
| Weight (t) | 1.5 | ||
| Truck chassis | Drive form | 8×4 | |
| Engine | Model | YC6A260-33YC water -cooled four strok diesel engine | |
| Rated power(KW) | 191 | ||
| Speed (r/min) | 2300 | ||
| Size (L*W*H)(mm) | 11510*2480*2800 | ||
| Electric generator | Model | MF | |
| Rated power (kw) | 15 | ||
| Rated voltage(v) | 400 | ||
| Rated current(A) | 27 | ||
| Speed (r/min) | 1500 | ||
| Frequency(Hz) | 50 | ||
| Protection level | IP21 | ||
| Insulation Class | H | ||
| The highest speed(Km/h) | 75 | ||
| Weight (kg) | 19340 | ||
| Transport size(L*W*H)(mm) | 11981x2480x3870 | ||
| Working size(L*W*H)(mm) | 11145x2480x13289 | ||
