1. Electric Airport Fire Truck
This vehicle is a special fire-fighting vehicle for the airport. It has strong power and excellent road passing ability. It can arrive safely and quickly for fire-fighting and rescue.The detailed parameters are as follows.
2. The Whole Fire Truck's Parameters
| No. | Main Items | Technical Parameters |
| 2.1 | Model | SXF5282GXFJX120 |
| 2.2 | Overall Dimension | 11700mm×3160mm×3960mm |
| 2.3 | Full Load Weight | 39000kgs |
| 2.4 | Number of the Crew | 2 (include driver) |
| 2.5 | Max. Speed | 130km/h |
| 2.6 | Capacity | 11000L Water & 1000L Foam. PP composite material liquid tank |
| 2.7 | Fire pump flow rate | 100L/s @ 10bar |
| 2.8 | Fire monitor | Front mounted monitor 20L/s, roof mounted monitor 80L/s |
| 2.9 | Painting | Fire Red |
3. Chassis
- Manufacturer:CHUANXIAO
- Model: Electric drive airport special fire truck chassis
- Drive type: 6*6
- Wheelbase: 4750mm+1600mm
- Rated power: 500(kW/rpm)
Power:
- Peak power: 1000kW
- Continuous power: 500kW
- Continuous torque: 4800 N.m
- Peak torque: 9600 N.m
- Operating temperature range -20°C to +50°C.
- Maximum speed: 3000rpm.
| No. | Main Items | Technical Parameters |
| 4.1 | Cabin | |
| 4.1.1 | Structure | Single row cabin with 2 doors |
| 4.1.2 | Seats | 2 seats with 3-point safety belt |
| 4.2 | Standardized Sub-frame | |
| 4.2.1 | Material | High-strength rectangular tube made of special steel |
| 4.2.2 | Performance | The liquid tank and the sub-frame are connected by elastic connecting seats |
| 4.3 | Compartment | |
| 4.3.1 | Material | High-strength aluminum alloy profiles |
| 4.3.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With aluminum alloy ladder in the rear |
| 4.4 | Roller Shutter Door | |
| 4.4.1 | Material | Aluminum alloy profiles with anodized surface |
| 4.4.2 | Structure | With rain-proof groove on the top, lever-type bar, lock handle, pull strap, two-point fixed seat, LED light and sensors. |
| 4.4 | Superstructure Electric Appliance | |
| 4.4.1 | Warning Light and Siren | Long-row warning light and siren are mounted above cabin. The controller is installed in the driver's cabin. |
| 4.4.2 | Strobe Light | Mounted on the both sides of the compartment |
| 4.4.3 | External Lighting | LED lights are mounted on the both sides of the compartment |
| 4.4.4 | Roof Lighting | LED lights are mounted on the inside of the roof |
| 4.4.5 | Side Indicator Light | Inline yellow warning light is mounted on the side of the compartment and pedals |
5.1 Fire Pump
- Flow Rate: 100L/s @ 10bar
- Vacuum Pump: Electric vacuum pump
- Priming Manner: Automatic
- Suction Height: 7m
- Priming Time: ≤100s
- Location: Rear-mounted
5.2 Fire Monitor
- Flow Rate: 80L/s @ 10bar
- Shoot Range: Water ≥ 75 m, Foam ≥ 70m
- Location: On the top of the tank
- Control Manner: Electric remote control
- Horizontal Rotation Angle 0°~300°
- Pitch Rotation Angle: -18°~65°
5.3 Liquid Tank
- Capacity: Water 11000L, Foam 1000L.
- Material: PP composite material and Never Rust.
- Structure: Two Tank Manhole; Two Overflow Device/Pressure Relief Device; Two Liquid Level Indicators; One Foam tank Drain Outlets with Valves; One Water tank Drain Outlets with Valves.
5.4 Control Panel
It adopts advanced CANBUS 2.0 bus control technology and is equipped with a pump room operation control panel and a handheld wireless operation terminal, which can realize functions such as one-click water dispensing, stable flow and pressure, and automatic adjustment of foam ratio.
CXFIRE, established in 1963, is the biggest fire trucks manufacturer in China with more than 60 years experience. The main manufacturing base is located in Chengdu of Sichuan Province with an area of 200,000 square meters and 600 staff members. More than 2000 units fire trucks and special vehicles are produced and sold every year.
CXFIRE has complete products system, including hundreds of fire trucks, fire equipment, fire fighting robots and other special vehicles. CXFIRE and its main products have obtained ISO, CCC, TUV, CE, EN and NFPA certifications.
CXFIRE products sell all over the world, including Asia, Middle East, Africa, Europe and America. CXFIRE has complete sales networks and after-sales service stations in global markets.
1. Complete Aluminum Compartment and Never Rust. The compartment uses high-quality aluminum alloy profile, and the integral welded frame structure is made by the patented technology. It has a built-in bolt connection and the space could be adjusted easily. It has the advantages of high strength, corrosion resistance and light weight. All harnesses are preset in the groove to avoid wear.
2. High-Quality PP Composite Material Liquid Tank and Never Rust. PP is a special plate made of polymer composite materials to create a liquid tank for fire truck. It has the advantages of high strength, impact resistance, low temperature resistance and corrosion resistance.
3. Modular Control System. The control system adopts PLC intelligent program design and full electronic control operation. Different control program modules are available to choose according to the vehicle configuration. With waterproof and dustproof design, the protection level can reach IP56 or higher.
4. Modular Standard Parts. Water pumps, fire monitors, aluminum roller shutter doors, storage racks and pipelines are all manufactured by CXFIRE with modular design. It can not only ensure the quality of parts and the best match with the whole vehicle, but also ensure generalization and flexibility.
