4LZ-6.0p For rice/wheat
After Sales Service and Training
Horizontal Cut Harvester
Rice, Corn, Wheat, Soybean
Diesel
Picking
Vee belt
Hard Shaft
Side Hanging Type
ISO9001:2008, CE
Red
New
Agriculture
1 Year Warranty
WORLD
Nude Packing
22CBM
China
84335100
Product Description
Feature:
1. All direction grain discharging pipe brings convenience.
2.102Hp engine, ZKB85 Gear Box and 45cc Domestic HST are used for making sure of work efficiency.
3. Fuel tank capacity 130L can meet the whole day's work.
4. Structure is compact, working is more flexible.
5. Min ground clearance 36cm and rubber track 550*90*56 ensure machines work faster in deep mud field.
Parameters as below,
About the World AM
1. All direction grain discharging pipe brings convenience.
2.102Hp engine, ZKB85 Gear Box and 45cc Domestic HST are used for making sure of work efficiency.
3. Fuel tank capacity 130L can meet the whole day's work.
4. Structure is compact, working is more flexible.
5. Min ground clearance 36cm and rubber track 550*90*56 ensure machines work faster in deep mud field.
Parameters as below,
| Model | 4LZ-6.0P | |
| Type | Self-propelled full feeding | |
| Dimension (Operation) | Length(mm) | 5150 |
| Width(mm) | 2890 | |
| Height(mm) | 3030 | |
| Weight(kg) | 3400Canopy | |
| Engine | Model | Changchai4G33TC |
| Type | Vertical, Water cool, Four-stroke, Direct Injection | |
| Power(HP) | 102 | |
| RPM(r/min) | 2600 | |
| Fuel tank(L) | 130 | |
| Gear Box Model | Hydraulic Gear Box ZKB85 | |
| HST | 45CC | |
| Walking Part | Track(mm) | 550*90*56 |
| Track Gauge(mm) | 1350 | |
| Ground Clearance(mm) | 360 | |
| Harvesting | Cutting Width(mm) | 2200 |
| Feeding Capacity (kg/s) | 6 | |
| Cutting Bar Lift | Hydraulic Control | |
| Threshing | Type | Axial Flow Type with Beat Bars |
| Threshing Cylinder (mm) | 620*2010 | |
| Cleaning Type | Vibrating Sieves+ Centrifugal Fan | |
| Discharging | Small Grain Tank (1.7.m3) | Auto Unloading,360Degrees |
| Work efficiency | (ha./h) | 0.5-0.9 |
| Crops | Rice, Wheat, Soybean,Rapeseed | |
