75HP 30HST
Combine Harvester
Rice, Wheat
New
75 - 77 HP
1 Year
High Productivity
Grain Harvester
2600kg
4.25m*2.4m*2.69m
1500 mm
Hot Product 2019
Not Available
300 - 1500 mm
Grain Reaper
Gearbox, Engine
Not Available
4
FM WORLD
3 Machines Per Container
Jiangsu, China
Product Description
PRODUCT SPECIFICATIONS
FMWORLD Head Feed DR150A Combine Harvester
Compact Dimension
Strong Engine Power
Simple Control
Easy Maintenance
Big Grain Tank
360° Unloading Pipe
Lengthening Threshing Cylinder
The Best After-service Around World
77HP Changchai diesel Engine
| Model | Item | Data | DR150A | |||
| Type | Power | 37.5KW | head-feeding | |||
| Dimension | Lengthmm | 4250 | ||||
| (Operation) | ||||||
| 3 | Widthmm | 2400 | ||||
| 4 | Heightmm | 2690 | ||||
| Engine | Type | 96kN | Inline, Water-cool, Four-stroke, Direct, Injection | |||
| 6 | Power (HP) | 60kN | 77 | |||
| 7 | Rated Rotating Speed (r/min) | 6750ml | 2700 | |||
| 8 | Fuel Tank | 500N.m | 60 | |||
| Gear Box Model | Hydraulic Gear Box ZKB40 | |||||
| HST | 30cc | |||||
| Chassis | Track (mm) | 400*90*46 | ||||
| Track Gauge (mm) | 1000 | |||||
| Ground Clearance (mm) | 250 | |||||
| Header Platfrom | Cutting Width (mm) | 1500 | ||||
| Rows | 4 | |||||
| Cutting Bar Lift | Hydraulic Control | |||||
| Thresher | Type | Axial Flow Type | ||||
| Threshing Cylinder (mm) | 424*900 | |||||
| Separating Type | Vibrating Sieves+ Centrifugal Fan | |||||
| Grain Tank | Big Grain Tank (0.7m3 | Auto Grain Unloading | ||||
| Working Effciency (ha/h) | 0.4-0.5 | |||||
| Crops | Rice, Wheat | |||||
Company Profile
WORLD A/M has been dedicated to becoming a worldwide first-class agriculture machinery manufacture in the past decade. By high-quality products and customer-oriented service support, the company's products command a good market both at home and in 58 countries and regions overseas. So far, more than 350,000 WORLD machines have been sold and uesd globally.
Product Overview
SALES AND SERVICE NETWORK
Successful Project
Showroom in Myanmar
Showroom in India
Showroom in Thailand
SIMILAR PRODUCTS
Warranty Policy:
1. Since the buyer's final acceptance date, our company implements the products after sale service. The warranty period is one year. The engine, gearbox and chassis we provide 2 years warranty.
2. During the warranty period, our company provides free maintenance and replacement parts, if these parts or damages are out of quality problems.
1. Since the buyer's final acceptance date, our company implements the products after sale service. The warranty period is one year. The engine, gearbox and chassis we provide 2 years warranty.
2. During the warranty period, our company provides free maintenance and replacement parts, if these parts or damages are out of quality problems.
3. In the meantime, the machine should be under normal operation by the buyers. (Except for improper operation
or man-made damage by the buyers).
4. We can send the parts by courier if urgently needed while the buyer should pay the freight.
or man-made damage by the buyers).
4. We can send the parts by courier if urgently needed while the buyer should pay the freight.
