VIFT forklift, founded in 2010, is a Shanghai-based leading manufacturer specializing for handing equipment from product design, production, to after-sales services for material handling equipment suppliers worldwide.We offer a wide range of products to fulfil the individual need of every customer from occasional operations to multi-shift applications in warehouse or distribution centers at high frequency level. At VIFT Forklift, we commit to producing the right truck for each application.
| ELECTRIC FORKLIFT TRUCK | ||||||
| Standard | ||||||
| 1.1 Series | MK | MK | MK | MK | ||
| 1.2 Model | MK30 | MK30 | MK35 | MK40 | ||
| 1.3 Powertype | Battery | Battery | Balte | Batten | ||
| 1.4 Operationtype | Seated | Seated | Seated | Seated | ||
| 1.5 Rated capacity | Q(kg) | 3000 | 3000 | 3500 | 4000 | |
| 1.6 Load center | C(mm) | 500 | 500 | 500 | 500 | |
| "17Frontoverhang | x(mm) | 433 | 433 | 484 | 484 | |
| 1.8 | Wheelbase | y(mm) | 1700 | 1700 | 1800 | 180C |
| Weight | ||||||
| 2.1 Service weightincl.battery) | kg | 4370 | 4460 | 4870 | 5300 | |
| Wheel | ||||||
| 3.1 Wheel type | Pneumatic tyre | Pneumatic tyre | Solid tyre | Solid tyre | ||
| 3.2 Load wheel | mm | 18×7-8 | 18×7-8 | 18×7-8 | 18×7-8 | |
| 3.3 Drivewheel | mm | 23×9-10 | 23×9-10 | 23×10-1: | 23×10-12 | |
| 3.4 Number ofwheels,front/rtear'k=drive wheel)---------… | 2x/2 | 2x/2 | 2x/2 | 2x/2 | ||
| 3.5 Wheeltread diriveside............ | b10(mm) | 970 | 970 | 108 | 080 | |
| 3.6 Wheel tread,load side | b11(mm) | 960 | 960 | 990 | 990 | |
| Size | ||||||
| 4.1 Mast titing | a /β(") | 6/10 | 6/10 | 6/1C | 6/10 | |
| 4.2 Mast closed height | h1(mm | 2110 | 2110 | 2110 | 2110 | |
| 4.3 Freelift height | h2(mm | 145 | 145 | 150 | 150 | |
| 4.4 Liftheight | h3(mm | 3000 | 3000 | 3000 | 3000 | |
| 4.5 Mastextended height with load-backrest | h4(mm | 4256 | 4256 | 425 | 425 | |
| 4.6 Overhead guard height | h6(mm | 2130 | 2130 | 2130 | 213 | |
| 4.7 Seatheight | h7(mm | 1120 | 1120 | 112 | 120 | |
| 4.8 Overall length | L1(mm) | 3620 | 3620 | 377 | 377C | |
| 4,9 Lengthtoforkface ... | L2(mm) | 2550 | 2550 | 2700 | 270C | |
| 4.10 | Overall wicth | b1(mm) | 1200 | 1200 | 330 | 330 |
| A¹1 Fork size | l/e/s(mm) | 1070/125/45 | 1070/125/4 | 1070112515 | 1070/125/5C | |
| 4.12 Installation level | 3A | 3A | 3A | 3A | ||
| 4.13 Forkcarriage width | b3(mm) | 1100 | 1100 | 1100 | 1100 | |
| 4.14 Forkoutside width............ | b5(mm) | 250~1050 | 250~1050 | 250~1050 | 250~1050 | |
| 4.15 Mastground clearance | m1(mm) | 90 | 90 | 90 | 90 | |
| 4.16 Bodyground clearance | m2(mm) | 100 | 100 | 100 | 100 | |
| 4.17 Aislewidthfor pallet 1000*1200mm | Ast(mm) | 3920 | 3920 | 4190 | 4190 | |
| 418 Tuming radius | Wa(mm) | 2300 | 2300 | 2450 | 2450 | |
| Function | ||||||
| 5.1 Driving speed(load/unload) | km/h | 10/12 | 10/12 | 0/12 | 0/12 | |
| 5.2 Liftingspeedlload/unload)… | mm/s | 200/340 | 200/340 | 00/300 | 200/30 | |
| 5.3 Lowering speed(load/unload) | mm/s | 300/460 | 300/460 | 300/46C | 300746C | |
| 5.4 Max gradeability(load/unload)(S2-5min) | %(tanθ) | 14/15 | 4/15 | 4/15 | 4/15 | |
| 5.5 Braketype | Hydraulic | Hydraulic | Hydrauli | Hydrauli | ||
| Drive | ||||||
| 6.1 Driving motor(S2-60min) | kw | AC9. | AC11.75 | 314 | AC14 | |
| 6.2 Lifting motor(S3-15%) | kw | DC10 | DC10 | DC10 | DC10 | |
| 6.3 Battery voltage/capacity | V/Ah | 48/63( | 80/40 | 80/400 | 80/450 | |
| 6.4 | Battery weight | kg | 980 | 1070 | 107 | 195 |
| 6.5 Steering system | Hydraulic | Hydraulic | Hydraulic | Hydraulic | ||
| Other | ||||||
| 7.1 Lithium battery voltage/capacity | V/Ah | 48/450 | 80/450 | 80/450 | 80/450 | |
| 7.2 AC lifting motor(S3-15%) | kw | AC12 | AC13.5 | AC13.5 | AC13.5 | |
| Thestandard model data wil vary acordingto theconfiguration | ||||||
Q1: How long is the Warranty for VIFT product?
A1: VIFT provides 12 months or 1000 hours for the whole machine from on board time.
Q2: How about the delivery time?
A2: Usually VIFT producing time is 15- 20 days after we receive the advanced payment. For some standard products, we may have stock and could delivery immediately.
Q3: How about the continuous working time for the electric series forklifts ? And How long time to charge the battery full ?
A3: VIFT battery continuous working time is around 3-6 hours (working time depend on battery volume).It needs usually 8 - 12 hours to charge the battery, VIFT's charger is automatic, after the battery is full, it will stop working automatically.
Q4: Can VIFT provide customized products? OEM products or ODM products?
A4: Yes, VIFT can provide customized products per your request, both OEM and ODM are acceptable. We do a lots of non-standard products, welcome your special reqeust.
Q5: What's the specification of the chargers?
A5: Our chargers voltage could be 110V 220V 240 380V 415V ( 1 phase or 3 phases,50/60HZ). Power plug could be USA/UK/AUSTRALIA/EUPROPEAN standard.
Q6: Could we request our own color for the products?
A6: Yes, of course, you just need to offer us the RAL code.
